DIP Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Part Status | Circuit | Number of Positions | Voltage Rating | Actuator Type | Actuator Level | Current Rating (Amps) | Contact Material | Contact Finish | Height Above Board | Mounting Style | Termination Style | Operating Temperature | Pitch | Features | Washable |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
A6ER-2104SWITCH PIANO DIP SPST 0.025A 24V |
1,750 |
|
Datasheet |
A6ER | Tray | Obsolete | SPST | 2 | 24VDC | Piano | Raised | 25mA | - | Gold | 0.402" (10.20mm) | Through Hole, Right Angle | PC Pin | -20°C ~ 70°C | 0.100" (2.54mm), Full | Sealed - Flux Protection | No |
|
A6ER-3104SWITCH PIANO DIP SPST 0.025A 24V |
1,960 |
|
Datasheet |
A6ER | Tray | Obsolete | SPST | 3 | 24VDC | Piano | Raised | 25mA | - | Gold | 0.402" (10.20mm) | Through Hole, Right Angle | PC Pin | -20°C ~ 70°C | 0.100" (2.54mm), Full | Sealed - Flux Protection | No |
|
A6ER-4101SWITCH PIANO DIP SPST 0.025A 24V |
3,552 |
|
Datasheet |
A6ER | Tube | Obsolete | SPST | 4 | 24VDC | Piano | Flush, Recessed | 25mA | - | Gold | 0.402" (10.20mm) | Through Hole, Right Angle | PC Pin | -20°C ~ 70°C | 0.100" (2.54mm), Full | Sealed - Flux Protection | No |
|
|
A6ER-4104SWITCH PIANO DIP SPST 0.025A 24V |
2,877 |
|
Datasheet |
A6ER | Tube | Obsolete | SPST | 4 | 24VDC | Piano | Raised | 25mA | - | Gold | 0.402" (10.20mm) | Through Hole, Right Angle | PC Pin | -20°C ~ 70°C | 0.100" (2.54mm), Full | Sealed - Flux Protection | No |
|
|
A6ER-5101SWITCH PIANO DIP SPST 0.025A 24V |
2,731 |
|
Datasheet |
A6ER | Tray | Obsolete | SPST | 5 | 24VDC | Piano | Flush, Recessed | 25mA | - | Gold | 0.402" (10.20mm) | Through Hole, Right Angle | PC Pin | -20°C ~ 70°C | 0.100" (2.54mm), Full | Sealed - Flux Protection | No |
|
A6ER-6101SWITCH PIANO DIP SPST 0.025A 24V |
4,026 |
|
Datasheet |
A6ER | Tray | Obsolete | SPST | 6 | 24VDC | Piano | Flush, Recessed | 25mA | - | Gold | 0.402" (10.20mm) | Through Hole, Right Angle | PC Pin | -20°C ~ 70°C | 0.100" (2.54mm), Full | Sealed - Flux Protection | No |
|
A6ER-6104SWITCH PIANO DIP SPST 0.025A 24V |
2,937 |
|
Datasheet |
A6ER | Tube | Obsolete | SPST | 6 | 24VDC | Piano | Raised | 25mA | - | Gold | 0.402" (10.20mm) | Through Hole, Right Angle | PC Pin | -20°C ~ 70°C | 0.100" (2.54mm), Full | Sealed - Flux Protection | No |
|
|
A6ER-7101SWITCH PIANO DIP SPST 0.025A 24V |
1,605 |
|
Datasheet |
A6ER | Tray | Obsolete | SPST | 7 | 24VDC | Piano | Flush, Recessed | 25mA | - | Gold | 0.402" (10.20mm) | Through Hole, Right Angle | PC Pin | -20°C ~ 70°C | 0.100" (2.54mm), Full | Sealed - Flux Protection | No |
|
|
A6ER-8101SWITCH PIANO DIP SPST 0.025A 24V |
2,217 |
|
Datasheet |
A6ER | Tube | Obsolete | SPST | 8 | 24VDC | Piano | Flush, Recessed | 25mA | - | Gold | 0.402" (10.20mm) | Through Hole, Right Angle | PC Pin | -20°C ~ 70°C | 0.100" (2.54mm), Full | Sealed - Flux Protection | No |
|
A6ER-8104SWITCH PIANO DIP SPST 0.025A 24V |
1,272 |
|
Datasheet |
A6ER | Tube | Obsolete | SPST | 8 | 24VDC | Piano | Raised | 25mA | - | Gold | 0.402" (10.20mm) | Through Hole, Right Angle | PC Pin | -20°C ~ 70°C | 0.100" (2.54mm), Full | Sealed - Flux Protection | No |
|
|
A6ER-9101SWITCH PIANO DIP SPST 0.025A 24V |
2,707 |
|
Datasheet |
A6ER | Bag | Obsolete | SPST | 9 | 24VDC | Piano | Flush, Recessed | 25mA | - | Gold | 0.402" (10.20mm) | Through Hole, Right Angle | PC Pin | -20°C ~ 70°C | 0.100" (2.54mm), Full | Sealed - Flux Protection | No |
|
|
A6ER-9104SWITCH PIANO DIP SPST 0.025A 24V |
4,719 |
|
Datasheet |
A6ER | Tray | Obsolete | SPST | 9 | 24VDC | Piano | Raised | 25mA | - | Gold | 0.402" (10.20mm) | Through Hole, Right Angle | PC Pin | -20°C ~ 70°C | 0.100" (2.54mm), Full | Sealed - Flux Protection | No |
|
A6S-0101SWITCH SLIDE DIP SPST 0.025A 24V |
2,475 |
|
Datasheet |
A6S | Bag | Obsolete | SPST | 10 | 24VDC | Slide (Standard) | Flush, Recessed | 25mA | - | - | 0.146" (3.70mm) | Surface Mount | Gull Wing | -20°C ~ 70°C | 0.100" (2.54mm), Full | - | No |
|
A6S-2101SWITCH SLIDE DIP SPST 0.025A 24V |
1,217 |
|
Datasheet |
A6S | Bag | Obsolete | SPST | 2 | 24VDC | Slide (Standard) | Flush, Recessed | 25mA | - | - | 0.146" (3.70mm) | Surface Mount | Gull Wing | -20°C ~ 70°C | 0.100" (2.54mm), Full | - | No |
|
A6S-3101SWITCH SLIDE DIP SPST 0.025A 24V |
1,661 |
|
Datasheet |
A6S | Bag | Obsolete | SPST | 3 | 24VDC | Slide (Standard) | Flush, Recessed | 25mA | - | - | 0.146" (3.70mm) | Surface Mount | Gull Wing | -20°C ~ 70°C | 0.100" (2.54mm), Full | - | No |
|
|
A6S-3102SWITCH SLIDE DIP SPST 0.025A 24V |
3,653 |
|
Datasheet |
A6S | Bag | Obsolete | SPST | 3 | 24VDC | Slide (Standard) | Flush, Recessed | 25mA | - | - | 0.146" (3.70mm) | Surface Mount | Gull Wing | -20°C ~ 70°C | 0.100" (2.54mm), Full | Tape Seal | Yes |
|
A6S-3104SWITCH SLIDE DIP SPST 0.025A 24V |
4,286 |
|
Datasheet |
A6S | Bag | Obsolete | SPST | 3 | 24VDC | Slide (Standard) | Raised | 25mA | - | - | 0.173" (4.40mm) | Surface Mount | Gull Wing | -20°C ~ 70°C | 0.100" (2.54mm), Full | - | No |
|
A6S-4101SWITCH SLIDE DIP SPST 0.025A 24V |
1,469 |
|
Datasheet |
A6S | Bag | Obsolete | SPST | 4 | 24VDC | Slide (Standard) | Flush, Recessed | 25mA | - | - | 0.146" (3.70mm) | Surface Mount | Gull Wing | -20°C ~ 70°C | 0.100" (2.54mm), Full | - | No |
|
A6S-5101SWITCH SLIDE DIP SPST 0.025A 24V |
1,488 |
|
Datasheet |
A6S | Bag | Obsolete | SPST | 5 | 24VDC | Slide (Standard) | Flush, Recessed | 25mA | - | - | 0.146" (3.70mm) | Surface Mount | Gull Wing | -20°C ~ 70°C | 0.100" (2.54mm), Full | - | No |
|
A6S-6101SWITCH SLIDE DIP SPST 0.025A 24V |
2,033 |
|
Datasheet |
A6S | Bag | Obsolete | SPST | 6 | 24VDC | Slide (Standard) | Flush, Recessed | 25mA | - | - | 0.146" (3.70mm) | Surface Mount | Gull Wing | -20°C ~ 70°C | 0.100" (2.54mm), Full | - | No |
