| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Part Status | Type | Count | Voltage - Supply | Current - Supply | Operating Temperature | Frequency | Supplier Device Package | Mounting Style | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
JM38510/10902BCADUAL PRECISION TIMER 14-CDIP -55 |
2,905 |
|
Datasheet |
- | 14-CDIP (0.300", 7.62mm) | Tube | Active | 555 Type, Timer/Oscillator (Dual) | - | 4.5V ~ 18V | 20 mA | -55°C ~ 125°C (TA) | - | 14-CDIP | Through Hole | - | - |
|
CD4536BF3ACMOS PROGRAMMABLE TIMER 16-CDIP |
1,375 |
|
Datasheet |
- | 16-CDIP (0.300", 7.62mm) | Tube | Active | Programmable Timer | 2 ~ 2²4 | 3V ~ 18V | 100 µA | -55°C ~ 125°C (TA) | 5MHz | 16-CDIP | Through Hole | - | - |
|
NE556NSPROTOTYPE |
1,162 |
|
Datasheet |
- | 14-SOIC (0.209", 5.30mm Width) | Bulk | Active | 555 Type, Timer/Oscillator (Dual) | - | 4.5V ~ 16V | 20 mA | 0°C ~ 70°C (TA) | - | 14-SO | Surface Mount | - | - |
|
SN74LS628NSPROTOTYPE |
4,686 |
|
Datasheet |
74LS | 14-SOIC (0.209", 5.30mm Width) | Tube | Active | VCO | - | 4.75V ~ 5.25V | 20 mA | 0°C ~ 70°C (TA) | 25MHz | 14-SO | Surface Mount | - | - |
|
SN74LS629NSPROTOTYPE |
2,942 |
|
Datasheet |
74LS | 16-SOIC (0.209", 5.30mm Width) | Tube | Active | VCO | - | 4.75V ~ 5.25V | 35 mA | 0°C ~ 70°C (TA) | 25MHz | 16-SO | Surface Mount | - | - |
|
NE555P-NGPROTOTYPE |
3,653 |
|
Datasheet |
- | 8-DIP (0.300", 7.62mm) | Bulk | Obsolete | 555 Type, Timer/Oscillator (Single) | - | 4.5V ~ 16V | 15 mA | 0°C ~ 70°C (TA) | 1mHz ~ 100kHz | 8-PDIP | Through Hole | - | - |
|
|
SE556JDUAL PRECISION TIMER 14-CDIP -55 |
4,441 |
|
Datasheet |
- | 14-CDIP (0.300", 7.62mm) | Tube | Active | 555 Type, Timer/Oscillator (Dual) | - | 4.5V ~ 18V | 20 mA | -55°C ~ 125°C (TA) | - | 14-CDIP | Through Hole | - | - |
|
CD4541BFCMOS PROGRAMMABLE TIMER - HIGH V |
2,247 |
|
Datasheet |
- | 14-CDIP (0.300", 7.62mm) | Tube | Active | Programmable Timer | 65536 | 3V ~ 18V | 100 µA | -55°C ~ 125°C (TA) | 100kHz ~ 6MHz | 14-CDIP | Through Hole | - | - |
|
|
M38510/10902BCADUAL PRECISION TIMER 14-CDIP -55 |
4,913 |
|
Datasheet |
- | 14-CDIP (0.300", 7.62mm) | Tube | Active | 555 Type, Timer/Oscillator (Dual) | - | 4.5V ~ 18V | 20 mA | -55°C ~ 125°C (TA) | - | 14-CDIP | Through Hole | - | - |
|
M38510/10901BPAPRECISION TIMER 8-CDIP -55 TO 12 |
4,825 |
|
Datasheet |
- | 8-CDIP (0.300", 7.62mm) | Tube | Active | 555 Type, Timer/Oscillator (Single) | - | 4.5V ~ 18V | 10 mA | -55°C ~ 125°C (TA) | 1mHz ~ 100kHz | 8-CDIP | Through Hole | - | - |
|
SN74LS624NSPROTOTYPE |
4,385 |
|
Datasheet |
74LS | 14-SOIC (0.209", 5.30mm Width) | Tube | Active | VCO | - | 4.75V ~ 5.25V | 20 mA | 0°C ~ 70°C (TA) | 25MHz | 14-SO | Surface Mount | - | - |
|
SE555FKBPRECISION TIMER 20-LCCC -55 TO 1 |
2,452 |
|
Datasheet |
- | 20-CLCC | Tube | Active | 555 Type, Timer/Oscillator (Single) | - | 4.5V ~ 18V | 12 mA | -55°C ~ 125°C (TA) | 1mHz ~ 100kHz | 20-LCCC (8.89x8.89) | Surface Mount | - | - |
|
|
CD4541BF3ACMOS PROGRAMMABLE TIMER - HIGH V |
2,103 |
|
Datasheet |
- | 14-CDIP (0.300", 7.62mm) | Tube | Active | Programmable Timer | 65536 | 3V ~ 18V | - | -55°C ~ 125°C (TA) | 100kHz | 14-CDIP | Through Hole | - | - |
|
|
SE556JBDUAL PRECISION TIMER 14-CDIP -55 |
2,161 |
|
Datasheet |
- | 14-CDIP (0.300", 7.62mm) | Tube | Active | 555 Type, Timer/Oscillator (Dual) | - | 4.5V ~ 18V | 20 mA | -55°C ~ 125°C (TA) | - | 14-CDIP | Through Hole | - | - |
|
|
SE555JGBPRECISION TIMER 8-CDIP -55 TO 12 |
3,494 |
|
Datasheet |
- | 8-CDIP (0.300", 7.62mm) | Tube | Active | 555 Type, Timer/Oscillator (Single) | - | 4.5V ~ 18V | 12 mA | -55°C ~ 125°C (TA) | 1mHz ~ 100kHz | 8-CDIP | Through Hole | - | - |
|
|
SE555JGPRECISION TIMER 8-CDIP -55 TO 12 |
1,991 |
|
Datasheet |
- | 8-CDIP (0.300", 7.62mm) | Tube | Active | 555 Type, Timer/Oscillator (Single) | - | 4.5V ~ 16.5V | 20 mA | -55°C ~ 125°C (TA) | - | 8-CDIP | Through Hole | - | - |
|
JM38510/10901BPAPRECISION TIMER 8-CDIP -55 TO 12 |
2,471 |
|
Datasheet |
- | 8-CDIP (0.300", 7.62mm) | Tube | Active | 555 Type, Timer/Oscillator (Single) | - | 4.5V ~ 18V | 10 mA | -55°C ~ 125°C (TA) | 1mHz ~ 100kHz | 8-CDIP | Through Hole | - | - |
|
|
SN54LS628JVOLTAGE-CONTROLLED OSCILLATORS 1 |
1,383 |
|
Datasheet |
54LS | 14-CDIP (0.300", 7.62mm) | Tube | Active | VCO | - | 4.5V ~ 5.5V | 20 mA | -55°C ~ 125°C (TA) | 15MHz ~ 25MHz | 14-CDIP | Through Hole | - | - |
|
SNJ54S124JDUAL VOLTAGE-CONTROLLED OSCILLAT |
2,502 |
|
Datasheet |
74S | 16-CDIP (0.300", 7.62mm) | Tube | Active | VCO (Dual) | - | 4.5V ~ 5.5V | 105 mA | -55°C ~ 125°C (TA) | 1Hz ~ 85MHz | 16-CDIP | Through Hole | - | - |
