| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Part Status | Base Resonator | Type | Function | Output | Voltage - Supply | Frequency | Frequency Stability | Absolute Pull Range (APR) | Operating Temperature | Spread Spectrum Bandwidth | Current - Supply (Max) | Size / Dimension | Ratings | Supplier Device Package | Mounting Style | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
S533025-24.000-X-LE2.00-RXTAL OSC XO 24.0000MHZ HCMOS SMD |
680 |
|
Datasheet |
S5 Low EMI | 4-SMD, No Lead | Cut Tape (CT) | Active | Crystal | XO (Standard) | Enable/Disable | HCMOS | 3.3V | 24 MHz | ±25ppm | - | -40°C ~ 85°C | ±2.00%, Center Spread | 20mA | 0.197" L x 0.126" W (5.00mm x 3.20mm) | - | - | Surface Mount | 0.051" (1.30mm) |
|
V73305100-24.576-RVCXO 24.576MHZ CMOS |
653 |
|
Datasheet |
V7 | 6-SMD, No Lead | Cut Tape (CT) | Active | Crystal | VCXO | Enable/Disable | HCMOS | 3.3V | 24.576 MHz | ±50ppm | ±100ppm | -20°C ~ 70°C | - | 25mA | 0.276" L x 0.197" W (7.00mm x 5.00mm) | - | - | Surface Mount | 0.075" (1.90mm) |
|
|
V733025150-24.576-RVCXO 24.576MHZ CMOS |
458 |
|
Datasheet |
V7 | 6-SMD, No Lead | Cut Tape (CT) | Active | Crystal | VCXO | Enable/Disable | HCMOS | 3.3V | 24.576 MHz | ±25ppm | ±150ppm | -20°C ~ 70°C | - | 25mA | 0.276" L x 0.197" W (7.00mm x 5.00mm) | - | - | Surface Mount | 0.075" (1.90mm) |
|
XLH735003.932160IXTAL OSC XO 3.93216MHZ HCMOS SMD |
373 |
|
Datasheet |
XPRESSO™ FXO-HC73 | 6-SMD, No Lead | Strip | Active | Crystal | XO (Standard) | Enable/Disable | HCMOS | 3.3V | 3.93216 MHz | ±50ppm | - | -40°C ~ 85°C | - | 32mA | 0.295" L x 0.205" W (7.50mm x 5.20mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.055" (1.40mm) |
|
|
XLH735019.200000IXTAL OSC XO 19.2000MHZ HCMOS SMD |
355 |
|
Datasheet |
XPRESSO™ FXO-HC73 | 6-SMD, No Lead | Strip | Active | Crystal | XO (Standard) | Enable/Disable | HCMOS | 3.3V | 19.2 MHz | ±50ppm | - | -40°C ~ 85°C | - | 32mA | 0.295" L x 0.205" W (7.50mm x 5.20mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.055" (1.40mm) |
|
|
XLH735059.941610IXTAL OSC XO 59.94161MHZ HCMOS |
326 |
|
Datasheet |
XPRESSO™ FXO-HC73 | 6-SMD, No Lead | Strip | Active | Crystal | XO (Standard) | Enable/Disable | HCMOS | 3.3V | 59.94161 MHz | ±50ppm | - | -40°C ~ 85°C | - | 47mA | 0.295" L x 0.205" W (7.50mm x 5.20mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.055" (1.40mm) |
|
HX51706001XTAL OSC XO 70.6560MHZ LVCMOS |
128 |
|
Datasheet |
SaRonix-eCera™ HX | 4-SMD, No Lead | Tape & Reel (TR) | Active | Crystal | XO (Standard) | Enable/Disable | LVCMOS | 3.3V | 70.656 MHz | ±50ppm | - | -40°C ~ 105°C | - | 40mA | 0.197" L x 0.126" W (5.00mm x 3.20mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.053" (1.35mm) |
|
SIT8208AC-G1-18E-50.000000XMEMS OSC XO 50.0000MHZ LVCMOS LV |
504 |
|
Datasheet |
SiT8208 | 4-SMD, No Lead | Tape & Reel (TR) | Active | MEMS | XO (Standard) | Enable/Disable | LVCMOS, LVTTL | 1.8V | 50 MHz | ±20ppm | - | -20°C ~ 70°C | - | 31mA | 0.106" L x 0.094" W (2.70mm x 2.40mm) | - | 4-SMD (2.7x2.4) | Surface Mount | 0.031" (0.80mm) |
|
XO6015XTAL OSC XO 25.0000MHZ CMOS SMD |
470 |
|
Datasheet |
- | 4-SMD, No Lead | Strip | Active | Crystal | XO (Standard) | Enable/Disable | CMOS | 1.2V | 25 MHz | ±25ppm | - | -40°C ~ 85°C | - | 6mA | 0.197" L x 0.126" W (5.00mm x 3.20mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.051" (1.30mm) |
|
SXO22C3C481-100.000MXTAL OSC XO 100.0000MHZ CMOS SMD |
1,630 |
|
Datasheet |
SXO22C | 4-SMD, No Lead | Bulk | Active | Crystal | XO (Standard) | Enable/Disable | CMOS | 3.3V | 100 MHz | ±25ppm | - | -40°C ~ 85°C | - | - | 0.098" L x 0.079" W (2.50mm x 2.00mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.039" (1.00mm) |
|
AU-48.000MBE-TXTAL OSC XO 48.0000MHZ CMOS SMD |
1,468 |
|
Datasheet |
AU | 4-SMD, No Lead | Tape & Reel (TR) | Active | Crystal | XO (Standard) | Enable/Disable | CMOS | 3.3V | 48 MHz | ±50ppm | - | -40°C ~ 85°C | - | 6mA | 0.126" L x 0.098" W (3.20mm x 2.50mm) | AEC-Q100 | - | Surface Mount | 0.043" (1.10mm) |
|
SIT1534AI-J4-DCC-00.032EMEMS OSC XO 32.0000HZ LVCMOS SMD |
1,355 |
|
Datasheet |
SiT1534 | 4-UFBGA, CSPBGA | Tape & Reel (TR) | Active | MEMS | XO (Standard) | - | LVCMOS | 1.2V ~ 3.63V | 32 Hz | ±100ppm | - | -40°C ~ 85°C | - | 1.4µA | 0.061" L x 0.033" W (1.54mm x 0.84mm) | - | 4-CSP (1.54x.84) | Surface Mount | 0.024" (0.60mm) |
|
|
STC53C33Q27-20.000MXTAL OSC TCXO 20.0000MHZ CMOS |
688 |
|
Datasheet |
STC53C | 4-SMD, No Lead | Bulk | Active | Crystal | TCXO | - | CMOS | 3.3V | 20 MHz | ±1.5ppm | - | -20°C ~ 70°C | - | 6mA | 0.197" L x 0.126" W (5.00mm x 3.20mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.059" (1.50mm) |
|
SVC75C3A07D2-27.000MXTAL OSC VCXO 27.0000MHZ CMOS |
566 |
|
Datasheet |
SVC75C | 6-SMD, No Lead | Bulk | Active | Crystal | VCXO | Enable/Disable | CMOS | 3.3V | 27 MHz | ±50ppm | ±50ppm | 0°C ~ 70°C | - | 25mA | 0.276" L x 0.197" W (7.00mm x 5.00mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.067" (1.70mm) |
|
SIT9003AI-23-28EB-25.00000XMEMS OSC XO 25.0000MHZ LVCMOS LV |
2,244 |
|
Datasheet |
SiT9003 | 4-SMD, No Lead | Tape & Reel (TR) | Active | MEMS | XO (Standard) | Enable/Disable | LVCMOS, LVTTL | 2.8V | 25 MHz | ±50ppm | - | -40°C ~ 85°C | - | 4.1mA | 0.126" L x 0.098" W (3.20mm x 2.50mm) | - | 4-PQFN (3.2x2.5) | Surface Mount | 0.031" (0.80mm) |
|
RTXE-2520ED333-C-50.000-TRXTAL OSC TCXO 50MHZ 3.3V HCMOS |
126 |
|
Datasheet |
RTXE-2520 | 4-SMD, No Lead | Tape & Reel (TR) | Active | Crystal | TCXO | Enable/Disable | HCMOS | 3.3V | 50 MHz | ±2.5ppm | ±1ppm | -40°C ~ 85°C | - | 7mA | 0.098" L x 0.079" W (2.50mm x 2.00mm) | - | - | Surface Mount | 0.039" (1.00mm) |
|
RB20M48000L001XTAL OSC XO 20.4800MHZ TTL TH |
500 |
|
Datasheet |
CO8 | 8-DIP, 4 Leads (Half Size) | Tube | Active | Crystal | XO (Standard) | Enable/Disable | TTL | 3.3V | 20.48 MHz | ±50ppm | - | -40°C ~ 85°C | - | 20mA | 0.520" L x 0.520" W (13.20mm x 13.20mm) | - | 4-VDFN (3.2x2.5) | Through Hole | 0.200" (5.08mm) |
|
CSX-750FCC44000000TXTAL OSC XO 44.0000MHZ CMOS TTL |
2,961 |
|
Datasheet |
CSX-750F | 4-SMD, No Lead | Tape & Reel (TR) | Obsolete | Crystal | XO (Standard) | Enable/Disable | CMOS, TTL | 5V | 44 MHz | ±100ppm | - | -20°C ~ 70°C | - | 45mA | 0.276" L x 0.197" W (7.00mm x 5.00mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.063" (1.60mm) |
|
|
CSX-750FCC45000000TXTAL OSC XO 45.0000MHZ CMOS TTL |
2,774 |
|
Datasheet |
CSX-750F | 4-SMD, No Lead | Tape & Reel (TR) | Obsolete | Crystal | XO (Standard) | Enable/Disable | CMOS, TTL | 5V | 45 MHz | ±100ppm | - | -20°C ~ 70°C | - | 45mA | 0.276" L x 0.197" W (7.00mm x 5.00mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.063" (1.60mm) |
|
|
TX22-M020S-38.400-X2-RXTAL OSC TCXO 38.4MHZ CLPSNW SMD |
1,000 |
|
Datasheet |
TX22 | 4-SMD, No Lead | Tape & Reel (TR) | Active | Crystal | TCXO | - | Clipped Sine Wave | 1.68V ~ 3.63V | 38.4 MHz | ±2ppm | - | -40°C ~ 105°C | - | 2.5mA | 0.098" L x 0.079" W (2.50mm x 2.00mm) | - | - | Surface Mount | 0.037" (0.95mm) |
