Oscillators
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Part Status | Base Resonator | Type | Function | Output | Voltage - Supply | Frequency | Frequency Stability | Absolute Pull Range (APR) | Operating Temperature | Spread Spectrum Bandwidth | Current - Supply (Max) | Size / Dimension | Ratings | Supplier Device Package | Mounting Style | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MXO45-3C-1M843200XTAL OSC XO 1.8432MHZ HCMOS TH |
237 |
|
Datasheet |
MXO45 | 14-DIP, 4 Leads (Full Size, Metal Can) | Tray | Active | Crystal | XO (Standard) | - | HCMOS, TTL | 5V | 1.8432 MHz | ±50ppm | - | -20°C ~ 70°C | - | 26mA | 0.819" L x 0.520" W (20.80mm x 13.20mm) | - | - | Through Hole | 0.240" (6.10mm) |
.jpg)
|
SG5032CCN 16.000000M-HJGA3XTAL OSC XO 16.0000MHZ CMOS SMD |
1,546 |
|
Datasheet |
SG5032CCN | 4-SMD, No Lead | Tape & Reel (TR) | Active | Crystal | XO (Standard) | Enable/Disable | CMOS | 4.5V ~ 5.5V | 16 MHz | ±50ppm | - | -40°C ~ 85°C | - | 20mA | 0.197" L x 0.126" W (5.00mm x 3.20mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.051" (1.30mm) |
|
SG3225CAN 50.0000M-TJGA3XTAL OSC XO 50.0000MHZ CMOS SMD |
1,910 |
|
Datasheet |
SG3225CAN | 4-SMD, No Lead | Tape & Reel (TR) | Active | Crystal | XO (Standard) | Enable/Disable | CMOS | 1.6V ~ 3.63V | 50 MHz | ±50ppm | - | -40°C ~ 85°C | - | 2.6mA | 0.126" L x 0.098" W (3.20mm x 2.50mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.047" (1.20mm) |
|
SG-210STF 50.0000MLXTAL OSC XO 50.0000MHZ CMOS SMD |
1,587 |
|
Datasheet |
SG-210STF | 4-SMD, No Lead | Strip | Active | Crystal | XO (Standard) | Standby (Power Down) | CMOS | 1.6V ~ 3.6V | 50 MHz | ±50ppm | - | -40°C ~ 85°C | - | 2.6mA | 0.098" L x 0.079" W (2.50mm x 2.00mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.035" (0.90mm) |
|
|
SG3225CAN 25.0000M-TDBA3XTAL OSC XO 25.0000MHZ CMOS SMD |
887 |
|
Datasheet |
SG3225CAN | 4-SMD, No Lead | Tape & Reel (TR) | Active | Crystal | XO (Standard) | Enable/Disable | CMOS | 1.6V ~ 3.63V | 25 MHz | ±25ppm | - | -20°C ~ 70°C | - | 2.2mA | 0.126" L x 0.098" W (3.20mm x 2.50mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.047" (1.20mm) |
|
|
SG3225CAN 50.0000M-TDBA3XTAL OSC XO 50.0000MHZ CMOS SMD |
684 |
|
Datasheet |
SG3225CAN | 4-SMD, No Lead | Tape & Reel (TR) | Active | Crystal | XO (Standard) | Enable/Disable | CMOS | 1.6V ~ 3.63V | 50 MHz | ±25ppm | - | -20°C ~ 70°C | - | 2.6mA | 0.126" L x 0.098" W (3.20mm x 2.50mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.047" (1.20mm) |
|
|
SG-210STF 12.0000ML3XTAL OSC XO 12.0000MHZ CMOS SMD |
578 |
|
Datasheet |
SG-210STF | 4-SMD, No Lead | Tape & Reel (TR) | Active | Crystal | XO (Standard) | Standby (Power Down) | CMOS | 1.6V ~ 3.6V | 12 MHz | ±50ppm | - | -40°C ~ 85°C | - | 1.8mA | 0.098" L x 0.079" W (2.50mm x 2.00mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.035" (0.90mm) |
|
ASDM1-27.000MHZ-LC-TMEMS OSC XO 27.0000MHZ LVCMOS |
16,828 |
|
Datasheet |
ASDM, Pure Silicon™ | 4-SMD, No Lead | Tape & Reel (TR) | Active | MEMS | XO (Standard) | Standby (Power Down) | LVCMOS | 3.3V | 27 MHz | ±50ppm | - | -40°C ~ 85°C | - | 15mA | 0.098" L x 0.079" W (2.50mm x 2.00mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.035" (0.90mm) |
|
ECS-TXO-2520-33-100-AN-TRXTAL OSC TCXO 10.0000MHZ HCMOS |
5,008 |
|
Datasheet |
ECS-TXO-2520 | 4-SMD, No Lead | Tape & Reel (TR) | Active | Crystal | TCXO | Enable/Disable | HCMOS | 3.3V | 10 MHz | ±2.5ppm | - | -40°C ~ 85°C | - | 4mA | 0.098" L x 0.079" W (2.50mm x 2.00mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.039" (1.00mm) |
|
|
ECS-TXO-2520-33-120-AN-TRXTAL OSC TCXO 12.0000MHZ HCMOS |
3,275 |
|
Datasheet |
ECS-TXO-2520 | 4-SMD, No Lead | Tape & Reel (TR) | Active | Crystal | TCXO | Enable/Disable | HCMOS | 3.3V | 12 MHz | ±2.5ppm | - | -40°C ~ 85°C | - | 4.8mA | 0.098" L x 0.079" W (2.50mm x 2.00mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.039" (1.00mm) |
|
ATXAIG-H13-F-40.000MHZ-F25-T3XTAL OSC TCXO 32 MHZ CMOS SMD |
1,480 |
|
Datasheet |
ATXAIG-H13 | 4-SMD, No Lead | Tape & Reel (TR) | Active | Crystal | TCXO | Enable/Disable | CMOS | 1.68V ~ 3.63V | 40 MHz | ±2.5ppm | - | -40°C ~ 85°C | - | 10mA | 0.079" L x 0.063" W (2.00mm x 1.60mm) | AEC-Q200 | 4-VDFN (3.2x2.5) | Surface Mount | 0.031" (0.80mm) |
|
ASD3-25.000MHZ-EC-TXTAL OSC XO 25.0000MHZ HCMOS SMD |
8,038 |
|
Datasheet |
ASD | 4-SMD, No Lead | Tape & Reel (TR) | Active | Crystal | XO (Standard) | Enable/Disable | HCMOS | 1.8V | 25 MHz | ±50ppm | - | -20°C ~ 70°C | - | 4mA | 0.098" L x 0.079" W (2.50mm x 2.00mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.039" (1.00mm) |
|
|
SG-210STF 32.0000ML3XTAL OSC XO 32.0000MHZ CMOS SMD |
4,424 |
|
Datasheet |
SG-210STF | 4-SMD, No Lead | Tape & Reel (TR) | Active | Crystal | XO (Standard) | Standby (Power Down) | CMOS | 1.6V ~ 3.6V | 32 MHz | ±50ppm | - | -40°C ~ 85°C | - | 2.2mA | 0.098" L x 0.079" W (2.50mm x 2.00mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.035" (0.90mm) |
|
ASDAIG-24.000MHZ-C-S-TOSC XO 24.000MHZ 3.3V CMOS SMD |
2,447 |
|
Datasheet |
ASDAIG | 4-SMD, No Lead | Tape & Reel (TR) | Active | Crystal | XO (Standard) | Enable/Disable | CMOS | 3.3V | 24 MHz | ±50ppm | - | -40°C ~ 125°C | - | 7mA | 0.098" L x 0.079" W (2.50mm x 2.00mm) | AEC-Q200 | - | Surface Mount | 0.037" (0.95mm) |
|
|
ASDAIG-27.000MHZ-C-S-TOSC XO 27.000MHZ 3.3V CMOS SMD |
1,296 |
|
Datasheet |
ASDAIG | 4-SMD, No Lead | Tape & Reel (TR) | Active | Crystal | XO (Standard) | Enable/Disable | CMOS | 3.3V | 27 MHz | ±50ppm | - | -40°C ~ 125°C | - | 7mA | 0.098" L x 0.079" W (2.50mm x 2.00mm) | AEC-Q200 | - | Surface Mount | 0.037" (0.95mm) |
|
XLH536200.000000IXTAL OSC XO 200.0000MHZ HCMOS |
406 |
|
Datasheet |
XPRESSO™ FXO-HC53 | 6-SMD, No Lead | Strip | Active | Crystal | XO (Standard) | Enable/Disable | HCMOS | 3.3V | 200 MHz | ±25ppm | - | -40°C ~ 85°C | - | 55mA | 0.203" L x 0.132" W (5.15mm x 3.35mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.055" (1.40mm) |
|
ASH7KW-32.768KHZ-L-TXTAL OSC XO 32.7680KHZ CMOS SMD |
1,127 |
|
Datasheet |
ASH7KW | 4-SMD, No Lead | Tape & Reel (TR) | Active | Crystal | XO (Standard) | Enable/Disable | CMOS | 1.2V ~ 5.5V | 32.768 kHz | - | - | -40°C ~ 85°C | - | 1.8µA (Typ) | 0.126" L x 0.059" W (3.20mm x 1.50mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.039" (1.00mm) |
|
|
ASDM1-25.000MHZ-LC-TMEMS OSC XO 25.0000MHZ LVCMOS |
15,104 |
|
Datasheet |
ASDM, Pure Silicon™ | 4-SMD, No Lead | Tape & Reel (TR) | Active | MEMS | XO (Standard) | Standby (Power Down) | LVCMOS | 3.3V | 25 MHz | ±50ppm | - | -40°C ~ 70°C | - | 15mA | 0.098" L x 0.079" W (2.50mm x 2.00mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.035" (0.90mm) |
|
|
ASDM1-50.000MHZ-LC-TMEMS OSC XO 50.0000MHZ LVCMOS |
13,684 |
|
Datasheet |
ASDM, Pure Silicon™ | 4-SMD, No Lead | Tape & Reel (TR) | Active | MEMS | XO (Standard) | Standby (Power Down) | LVCMOS | 3.3V | 50 MHz | ±50ppm | - | -40°C ~ 85°C | - | 15mA | 0.098" L x 0.079" W (2.50mm x 2.00mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.035" (0.90mm) |
|
|
ASDM1-10.000MHZ-LC-TMEMS OSC XO 10.0000MHZ LVCMOS |
8,329 |
|
Datasheet |
ASDM, Pure Silicon™ | 4-SMD, No Lead | Tape & Reel (TR) | Active | MEMS | XO (Standard) | Standby (Power Down) | LVCMOS | 3.3V | 10 MHz | ±50ppm | - | -40°C ~ 85°C | - | 15mA | 0.098" L x 0.079" W (2.50mm x 2.00mm) | - | 4-VDFN (3.2x2.5) | Surface Mount | 0.035" (0.90mm) |
