Reed Relays
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Part Status | Mounting Style | Coil Voltage | Contact Rating (Current) | Switching Voltage | Coil Current | Contact Form | Coil Type | Features | Termination Style | Seal Rating | Must Operate Voltage | Operating Temperature | Must Release Voltage | Release Time | Operate Time | Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BFM-1A-12ERELAY REED SPST .5A 12V |
2,671 |
|
Datasheet |
BFM | Tube | Active | Through Hole | 12VDC | 500 mA | 200VDC - Max | 8 mA | SPST-NO (1 Form A) | Non Latching | Electrostatic Shield | PC Pin | - | 9 VDC | -25°C ~ 85°C | 1 VDC | 0.1 ms | 0.5 ms | Ruthenium (Ru) |
|
V23100V4015A011RELAY REED SPST 500MA 15V |
1,003 |
|
Datasheet |
V23100-V4, AXICOM | Tube | Active | Through Hole | 15VDC | 500 mA | 200VAC, 200VDC - Max | 7.5 mA | SPST-NO (1 Form A) | Non Latching | Diode, Electrostatic Shield | PC Pin | - | 10.5 VDC | -40°C ~ 85°C | 2.25 VDC | 0.15 ms | 0.75 ms | Ruthenium (Ru) |
|
JWD-107-7RELAY REED SPST 500MA 12V |
4,005 |
|
Datasheet |
JWD | Tray | Discontinued | Through Hole | 12VDC | 500 mA | 100VDC - Max | 10 mA | SPST-NO (1 Form A) | Non Latching | Diode | PC Pin | - | 9.6 VDC | -35°C ~ 85°C | 1 VDC | 0.5 ms | 1.5 ms | Ruthenium (Ru) |
|
8L02-24-10RELAY REED DPST 500MA 24V |
4,015 |
|
Datasheet |
8L | Tube | Active | Through Hole | 24VDC | 500 mA | 200VAC, 200VDC - Max | 12 mA | DPST-NO (2 Form A) | Non Latching | Electrostatic Shield | PC Pin | - | 19.2 VDC | -20°C ~ 85°C | 2 VDC | 0.5 ms | 0.5 ms | - |
|
|
BFM-1A-05CRELAY REED SPST .5A 5V |
3,058 |
|
Datasheet |
BFM | Tube | Active | Through Hole | 5VDC | 500 mA | 200VDC - Max | 13.5 mA | SPST-NO (1 Form A) | Non Latching | - | PC Pin | - | 3.8 VDC | -25°C ~ 85°C | 0.4 VDC | 0.1 ms | 0.5 ms | Ruthenium (Ru) |
|
|
DIP-1C24200V/0.5A REED RELAY, 1 FORM C, |
2,249 |
|
Datasheet |
DIP | Active | Through Hole | 24VDC | 200 mA | 100VAC, 100VDC - Max | 12 mA | SPDT (1 Form C) | Non Latching | - | PC Pin | - | 18 VDC | -20°C ~ 85°C | 2 VDC | 2 ms | 1.5 ms | - | |
|
|
8L41-24-011RELAY REED SPDT 250MA 24V |
1,070 |
|
Datasheet |
8L | Tube | Active | Through Hole | 24VDC | 250 mA | 100VAC, 100VDC - Max | 12 mA | SPDT (1 Form C) | Non Latching | Diode | PC Pin | - | 19.2 VDC | -20°C ~ 85°C | 2 VDC | 1 ms | 1 ms | - |
|
8L61-12-001RELAY REED SPDT 250MA 12V |
1,604 |
|
Datasheet |
8L | Tube | Active | Surface Mount | 12VDC | 250 mA | 100VAC, 100VDC - Max | 24 mA | SPDT (1 Form C) | Non Latching | - | J Lead | - | 9.6 VDC | -20°C ~ 85°C | 1 VDC | 1 ms | 1 ms | - |
|
9104-12-30RELAY REED SPST 500MA 12V |
3,810 |
|
Datasheet |
9104 | Bulk | Active | Through Hole | 12VDC | 500 mA | 1000VAC, 1000VDC - Max | 24 mA | SPST-NO (1 Form A) | Non Latching | EMI Shielded | PC Pin | Sealed - Hermetically | 9 VDC | -20°C ~ 85°C | 1 VDC | 0.5 ms | 0.75 ms | - |
|
|
9104-05-30RELAY REED SPST 500MA 5V |
1,239 |
|
Datasheet |
9104 | Bulk | Active | Through Hole | 5VDC | 500 mA | 1000VAC, 1000VDC - Max | 28.6 mA | SPST-NO (1 Form A) | Non Latching | EMI Shielded | PC Pin | Sealed - Hermetically | 3.75 VDC | -20°C ~ 85°C | 0.5 VDC | 0.5 ms | 0.75 ms | - |
|
|
8L61-24-001RELAY 8000S SPARTAN |
1,764 |
|
Datasheet |
8L | Tube | Active | Through Hole | 24VDC | 250 mA | 100VAC, 100VDC - Max | 12 mA | SPDT (1 Form C) | Non Latching | - | PC Pin | Sealed - Hermetically | 19.2 VDC | -20°C ~ 85°C | 2 VDC | 1 ms | 1 ms | - |
|
BFH-2A-05RELAY REED DPST .5A 5V |
4,104 |
|
Datasheet |
BFH | Tube | Active | Through Hole | 5VDC | 500 mA | 200VDC - Max | 28.6 mA | DPST-NO (2 Form A) | Non Latching | - | PC Pin | - | 3.8 VDC | -20°C ~ 85°C | 0.4 VDC | 0.15 ms | 0.5 ms | Ruthenium (Ru) |
|
|
BFH 2A-12RELAY REED DPST .5A 12V |
2,229 |
|
Datasheet |
BFH | Tube | Active | Through Hole | 12VDC | 500 mA | 200VDC - Max | 12 mA | DPST-NO (2 Form A) | Non Latching | - | PC Pin | - | 9 VDC | -20°C ~ 85°C | 1 VDC | 0.15 ms | 0.5 ms | Ruthenium (Ru) |
|
|
9104-12-31RELAY REED SPST 500MA 12V |
1,833 |
|
Datasheet |
9104 | Bulk | Active | Through Hole | 12VDC | 500 mA | 1000VAC, 1000VDC - Max | 24 mA | SPST-NO (1 Form A) | Non Latching | Diode, EMI Shielded | PC Pin | Sealed - Hermetically | 9 VDC | -20°C ~ 85°C | 1 VDC | 0.5 ms | 0.75 ms | - |
|
|
9104-05-31RELAY REED SPST 500MA 5V |
1,477 |
|
Datasheet |
9104 | Bulk | Active | Through Hole | 5VDC | 500 mA | 1000VAC, 1000VDC - Max | 28.6 mA | SPST-NO (1 Form A) | Non Latching | Diode, EMI Shielded | PC Pin | Sealed - Hermetically | 3.75 VDC | -20°C ~ 85°C | 0.5 VDC | 0.5 ms | 0.75 ms | - |
|
3570-1517-051RELAY REED SIP SPST .5A 5V |
1,899 |
|
Datasheet |
3570 | Tube | Active | Through Hole | 5VDC | 500 mA | 170VDC - Max | 12.5 mA | SPST-NO (1 Form A) | Non Latching | - | PC Pin | - | 3.75 VDC | -40°C ~ 85°C | 0.4 VDC | 0.1 ms | 0.2 ms | - |
|
|
D31B5100REED RELAY 1B/12V |
4,888 |
|
Datasheet |
- | Tray | Active | Through Hole | 12VDC | 500 mA | 100VDC - Max | 12 mA | SPST-NC (1 Form B) | Non Latching | - | PC Pin | - | 9 VDC | -40°C ~ 70°C | 1 VDC | 50 µs | 1 ms | Rhodium (Rh) |
|
|
D31B3100REED RELAY 1B/5V |
3,011 |
|
Datasheet |
- | Tray | Active | Through Hole | 5VDC | 500 mA | 100VDC - Max | 10 mA | SPST-NC (1 Form B) | Non Latching | - | PC Pin | - | 4.2 VDC | -40°C ~ 70°C | 0.6 VDC | 50 µs | 1 ms | Rhodium (Rh) |
|
|
JWD-107-3RELAY REED SPST 500MA 12V |
3,391 |
|
Datasheet |
JWD | Tray | Active | Through Hole | 12VDC | 500 mA | 100VDC - Max | 10 mA | SPST-NO (1 Form A) | Non Latching | - | PC Pin | - | 9.6 VDC | -35°C ~ 85°C | 1 VDC | 0.5 ms | 1.5 ms | Ruthenium (Ru) |
|
JWS-117-5RELAY REED SPST 500MA 24V |
2,923 |
|
Datasheet |
JWS | Tube | Active | Through Hole | 24VDC | 500 mA | 100VDC - Max | 11.2 mA | SPST-NO (1 Form A) | Non Latching | - | PC Pin | - | 19.2 VDC | -35°C ~ 85°C | 2 VDC | 0.5 ms | 1.5 ms | Ruthenium (Ru) |
