| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Part Status | Number of Positions | Index Stops | Number of Poles per Deck | Circuit per Deck | Contact Timing | Number of Decks | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Actuator Length | Mounting Style | Angle of Throw | Contact Finish | Contact Material | Termination Style | Features | Depth Behind Panel |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
50A90-01-1-03NSWITCH ROTARY 3POS 150MA 115V |
1,416 |
|
Datasheet |
50 | Bulk | Active | 3 | Fixed | 1 | SP3T | Non-Shorting (BBM) | 1 | 150mA (AC), 200mA (DC) | 115 V | 28 V | Flatted (3.17mm Dia) | 9.53mm | Panel Mount | 90° | Gold | - | Solder Lug | - | 18.77mm |
|
|
50A90-01-1-04NSWITCH ROTARY 4POS 150MA 115V |
1,234 |
|
Datasheet |
50 | Bulk | Active | 4 | Continuous | 1 | SP4T | Non-Shorting (BBM) | 1 | 150mA (AC), 200mA (DC) | 115 V | 28 V | Flatted (3.17mm Dia) | 9.53mm | Panel Mount | 90° | Gold | - | Solder Lug | - | 18.77mm |
|
|
50BP36-01-1-10NSWITCH ROTARY 10POS 150MA 115V |
4,925 |
|
Datasheet |
50 | Bulk | Active | 10 | Continuous | 1 | SP10T | Non-Shorting (BBM) | 1 | 150mA (AC), 200mA (DC) | 115 V | 28 V | Screwdriver Slot | 3.18mm | Panel Mount, Through Hole | 36° | Gold | - | PC Pin | - | 13.64mm |
|
|
50P36-01-1-02NSWITCH ROTARY 2POS 150MA 115V |
3,923 |
|
Datasheet |
50 | Bulk | Active | 2 | Fixed | 1 | SPDT | Non-Shorting (BBM) | 1 | 150mA (AC), 200mA (DC) | 115 V | 28 V | Flatted (3.17mm Dia) | 9.53mm | Panel Mount, Through Hole | 36° | Gold | - | PC Pin | - | 13.64mm |
|
|
50P36-01-1-03NSWITCH ROTARY 3POS 150MA 115V |
3,839 |
|
Datasheet |
50 | Bulk | Active | 3 | Fixed | 1 | SP3T | Non-Shorting (BBM) | 1 | 150mA (AC), 200mA (DC) | 115 V | 28 V | Flatted (3.17mm Dia) | 9.53mm | Panel Mount, Through Hole | 36° | Gold | - | PC Pin | - | 13.64mm |
|
|
50P36-01-1-04NSWITCH ROTARY 4POS 150MA 115V |
2,426 |
|
Datasheet |
50 | Bulk | Active | 4 | Fixed | 1 | SP4T | Non-Shorting (BBM) | 1 | 150mA (AC), 200mA (DC) | 115 V | 28 V | Flatted (3.17mm Dia) | 9.53mm | Panel Mount, Through Hole | 36° | Gold | - | PC Pin | - | 13.64mm |
|
|
50P36-01-1-05NSWITCH ROTARY 5POS 150MA 115V |
3,613 |
|
Datasheet |
50 | Bulk | Active | 5 | Fixed | 1 | SP5T | Non-Shorting (BBM) | 1 | 150mA (AC), 200mA (DC) | 115 V | 28 V | Flatted (3.17mm Dia) | 9.53mm | Panel Mount, Through Hole | 36° | Gold | - | PC Pin | - | 13.64mm |
|
|
50P36-01-1-06NSWITCH ROTARY 6POS 150MA 115V |
1,789 |
|
Datasheet |
50 | Bulk | Active | 6 | Fixed | 1 | SP6T | Non-Shorting (BBM) | 1 | 150mA (AC), 200mA (DC) | 115 V | 28 V | Flatted (3.17mm Dia) | 9.53mm | Panel Mount, Through Hole | 36° | Gold | - | PC Pin | - | 13.64mm |
|
|
50P36-01-1-08NSWITCH ROTARY 8POS 150MA 115V |
1,104 |
|
Datasheet |
50 | Bulk | Active | 8 | Fixed | 1 | SP8T | Non-Shorting (BBM) | 1 | 150mA (AC), 200mA (DC) | 115 V | 28 V | Flatted (3.17mm Dia) | 9.53mm | Panel Mount, Through Hole | 36° | Gold | - | PC Pin | - | 13.64mm |
|
|
50P36-01-1-10NSWITCH ROTARY 10POS 150MA 115V |
3,155 |
|
Datasheet |
50 | Bulk | Active | 10 | Continuous | 1 | SP10T | Non-Shorting (BBM) | 1 | 150mA (AC), 200mA (DC) | 115 V | 28 V | Flatted (3.17mm Dia) | 9.53mm | Panel Mount, Through Hole | 36° | Gold | - | PC Pin | - | 13.64mm |
|
|
50P36-01-1-10N-FSWITCH ROTARY 10POS 150MA 115V |
3,464 |
|
Datasheet |
50 | Bulk | Active | 10 | Fixed | 1 | SP10T | Non-Shorting (BBM) | 1 | 150mA (AC), 200mA (DC) | 115 V | 28 V | Flatted (3.17mm Dia) | 9.53mm | Panel Mount, Through Hole | 36° | Gold | - | PC Pin | - | 13.64mm |
|
MB00S1NZGDSWITCH ROTARY 5POS 0.4VA 20V |
2,857 |
|
Datasheet |
M | Bulk | Active | 5 | Fixed | 2 | DP5T | Non-Shorting (BBM) | 1 | 0.4VA (AC/DC) | 20 V | 20 V | Flatted (3.17mm Dia) | 10.16mm | Panel Mount | 36° | Gold | Copper Alloy | Solder Lug | - | 15.88mm |
|
|
MA06L1NCGDSWITCH ROTARY 6POS 250MA 125V |
2,892 |
|
Datasheet |
M | Tray | Active | 6 | Fixed | 1 | SP6T | Non-Shorting (BBM) | 1 | 250mA (AC/DC) | 125 V | 28 V | Flatted (3.17mm Dia) | 10.16mm | Panel Mount, Through Hole | 36° | Gold | Copper Alloy | PC Pin | - | 10.42mm |
|
|
MC03S2NZQDSWITCH ROTARY 3POS 250MA 125V |
4,890 |
|
Datasheet |
M | Tray | Active | 3 | Fixed | 1 | SP3T | Non-Shorting (BBM) | 1 | 250mA (AC/DC) | 125 V | 28 V | Screwdriver Slot | Flush | Panel Mount | 30° | Silver | Copper Alloy | Solder Lug | - | 14.86mm |
|
MG00S1NCQDSWITCH ROTARY 12POS 250MA 125V |
2,776 |
|
Datasheet |
M | Tray | Active | 12 | Continuous | 1 | SP12T | Non-Shorting (BBM) | 1 | 250mA (AC/DC) | 125 V | 28 V | Flatted (3.17mm Dia) | 10.16mm | Panel Mount, Through Hole | 30° | Silver | Copper Alloy | PC Pin | - | 11.44mm |
|
MRJB4304SWITCH ROTARY 3POS 0.4VA 20V |
2,211 |
|
Datasheet |
MRJ | Tray | Obsolete | 3 | Fixed | 4 | 4P3T | Non-Shorting (BBM) | 1 | 0.4VA (AC/DC) | 20 V | 20 V | Screwdriver Slot | 1.02mm | Through Hole | 30° | Gold | Nickel | PC Pin | Epoxy Sealed Terminals | 7.62mm |
|
|
MG00S1NZGFSWITCH ROTARY 12POS 250MA 125V |
1,726 |
|
Datasheet |
M | Tray | Active | 12 | Continuous | 1 | SP12T | Non-Shorting (BBM) | 1 | 250mA (AC/DC) | 125 V | 28 V | Flatted (3.17mm Dia) | 10.16mm | Panel Mount | 30° | Gold | Copper Alloy | Solder Lug | IP67 - Dust Tight, Waterproof | 15.88mm |
|
|
56SDP30-01-1-AJSSWITCH ROTARY 2-12POS 200MA 115V |
4,998 |
|
Datasheet |
56 | Bulk | Active | 2 ~ 12 | Adjustable | 1 | SP12T | Shorting (MBB) | 1 | 200mA (AC/DC) | 115 V | 30 V | Flatted (3.17mm Dia) | 9.53mm | Panel Mount, Through Hole | 30° | Silver | Brass | PC Pin | Shaft and Panel Sealed | 9.58mm |
|
|
MA00L3NZGFSWITCH ROTARY 10POS 250MA 125V |
2,814 |
|
Datasheet |
M | Tray | Active | 10 | Continuous | 1 | SP10T | Non-Shorting (BBM) | 1 | 250mA (AC/DC) | 125 V | 28 V | Round (3.17mm Dia) | 10.16mm | Panel Mount | 36° | Gold | Copper Alloy | Solder Lug | IP67 - Dust Tight, Waterproof | 14.86mm |
|
|
56A30-01-2-04NSWITCH ROTARY 4POS 200MA 115V |
2,077 |
|
Datasheet |
56 | Bulk | Active | 4 | Fixed | 2 | DP4T | Non-Shorting (BBM) | 1 | 200mA (AC/DC) | 115 V | 30 V | Flatted (3.17mm Dia) | 9.53mm | Panel Mount | 30° | Silver | Brass | Solder Lug | - | 12.19mm |
