| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Part Status | Circuit | Contact Timing | Current Rating (Amps) | Voltage Rating - DC | Actuator Type | Switch Function | Actuator Length | Contact Material | Contact Finish | Mounting Style | Termination Style | Features | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
600SP1S2M1QSWITCH SLIDE SPDT 1A 30V |
1,694 |
|
Datasheet |
600 | Bulk | Active | SPDT | Not Specified | 1A (DC) | - | 30 V | On-On | Standard | 2.81mm | Copper Alloy | Silver | Through Hole | PC Pin | Epoxy Sealed Terminals, IP67 |
|
|
600SP3S2M1QSWITCH SLIDE SPDT 1A 30V |
1,999 |
|
Datasheet |
600 | Bulk | Active | SPDT | Not Specified | 1A (DC) | - | 30 V | On-Off-On | Standard | 2.81mm | Copper Alloy | Silver | Through Hole | PC Pin | IP67 - Dust Tight, Waterproof |
|
G-1328S-0025SWITCH SLIDE DP3T 13A 125V |
3,916 |
|
Datasheet |
G | Bulk | Active | DP3T | Not Specified | 13A (AC), 500mA (DC) | 125 V | 125 V | On-On-On | Standard | 8.74mm | Copper | Silver | Panel Mount | Solder Lug | - |
|
|
GF-642-0000SWITCH SLIDE 4PDT 6A 125V |
4,583 |
|
Datasheet |
GF | Bulk | Active | 4PDT | Not Specified | 6A (AC), 500mA (DC) | 125 V | 125 V | On-On | Standard | 8.74mm | Copper | Silver | Panel Mount | Solder Lug | - |
|
|
S102031MS03QS102031MS03Q |
2,167 |
|
Datasheet |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
SLS141PCSWITCH SLIDE SP4T 250MA 125V |
4,085 |
|
Datasheet |
SLS | Bulk | Obsolete | SP4T | Non-Shorting (BBM) | 250mA (AC), 150mA (DC) | 125 V | 12 V | On-On-On-On | Standard | 5.00mm | Copper Alloy | Silver | Through Hole | PC Pin | Epoxy Sealed Terminals |
|
|
G-375A-0016SWITCH SLIDE DPDT 3A 125V |
4,926 |
|
Datasheet |
G | Bulk | Active | DPDT | Not Specified | 3A (AC), 500mA (DC) | 125 V | 125 V | On-Mom | Standard | 19.05mm | Copper | Silver | Panel Mount | PC Pin | - |
|
|
G-1338S-0011SWITCH SLIDE DP4T 13A 125V |
3,374 |
|
Datasheet |
G | Bulk | Active | DP4T | Not Specified | 13A (AC), 500mA (DC) | 125 V | 125 V | On-On-On-On | Standard | 8.74mm | Copper | Silver | Panel Mount | Solder Lug | Gray Actuator |
|
|
GF-361-0019SWITCH SLIDE 3PDT 3A 125V |
1,092 |
|
Datasheet |
GF | Bulk | Active | 3PDT | Not Specified | 3A (AC), 500mA (DC) | 125 V | 125 V | On-On | Screwdriver Slot | 0.79mm | Copper | Silver | Panel Mount | Solder Lug | - |
|
|
GF-361-0025SWITCH SLIDE 3PDT 3A 125V |
2,338 |
|
Datasheet |
GF | Bulk | Active | 3PDT | Not Specified | 3A (AC), 500mA (DC) | 125 V | 125 V | On-On | Standard | 8.74mm | Copper | Silver | Panel Mount | Solder Lug | - |
|
L101021MS02QSWITCH SLIDE SPST 4A 125V |
3,415 |
|
Datasheet |
L | Bulk | Active | SPST | Not Specified | 4A (AC/DC) | 125 V | 28 V | On-Off | Standard | 8.51mm | Copper | Silver | Through Hole | PC Pin | - |
|
|
3-1437577-7SWITCH SLIDE DPDT 500MA 125V |
1,063 |
|
Datasheet |
SLS | Bulk | Obsolete | DPDT | Non-Shorting (BBM) | 500mA (AC) | 125 V | - | On-On | Standard | 4.80mm | Copper Alloy | Silver | Panel Mount | Solder Lug | Epoxy Sealed Terminals |
|
MSS1200RGSWITCH SLIDE SPDT 0.4VA 20V |
2,068 |
|
Datasheet |
MSS | Bulk | Obsolete | SPDT | Shorting (MBB) | 0.4VA (AC/DC) | 20 V | 20 V | On-On | Standard | 4.00mm | Copper Alloy | Gold | Through Hole, Right Angle | PC Pin | Epoxy Sealed Terminals |
|
|
GF-361-0049SWITCH SLIDE 3PDT 3A 125V |
2,151 |
|
Datasheet |
GF | Bulk | Active | 3PDT | Not Specified | 3A (AC), 500mA (DC) | 125 V | 125 V | On-On | Standard | 4.78mm | Copper | Silver | Panel Mount | PC Pin | - |
|
|
1825082-1SWITCH SLIDE SPDT 500MA 125V |
3,552 |
|
Datasheet |
SLSA | Bulk | Obsolete | SPDT | Non-Shorting (BBM) | 500mA (AC) | 125 V | - | On-On | Standard | 3.20mm | Copper Alloy | Silver | Through Hole | Solder Turret | Epoxy Sealed Terminals |
|
|
GF-1161-0000SWITCH SLIDE 3PDT 11A 125V |
2,307 |
|
Datasheet |
GF | Bulk | Active | 3PDT | Not Specified | 11A (AC), 500mA (DC) | 125 V | 125 V | On-On | Standard | 8.74mm | Copper | Silver | Panel Mount | Solder Lug | - |
|
|
1102A1CQEASWITCH SLIDE SPDT 5A 120V |
3,879 |
|
Datasheet |
1000 | Bag | Active | SPDT | Not Specified | 5A (AC/DC) | 120 V | 28 V | On-Mom | Standard | 5.08mm | Copper Alloy | Silver | Through Hole | PC Pin | - |
|
|
1102A2BQEBSWITCH SLIDE SPDT 5A 120V |
3,475 |
|
Datasheet |
1000 | Bag | Active | SPDT | Not Specified | 5A (AC/DC) | 120 V | 28 V | On-Mom | Standard | 7.24mm | Copper Alloy | Silver | Panel Mount | Solder Lug | - |
|
|
1102A1BQEBSWITCH SLIDE SPDT 5A 120V |
4,738 |
|
Datasheet |
1000 | Bag | Active | SPDT | Not Specified | 5A (AC/DC) | 120 V | 28 V | On-Mom | Standard | 5.08mm | Copper Alloy | Silver | Panel Mount | Solder Lug | - |
|
|
1102A2CQEASWITCH SLIDE SPDT 5A 120V |
4,265 |
|
Datasheet |
1000 | Bag | Active | SPDT | Not Specified | 5A (AC/DC) | 120 V | 28 V | On-Mom | Standard | 7.24mm | Copper Alloy | Silver | Through Hole | PC Pin | - |
