Trimmers, Variable Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Part Status | Capacitance Range | Adjustment Type | Dielectric Material | Q @ Freq | Size / Dimension | Voltage - Rated | Height - Seated (Max) | Operating Temperature | Mounting Style | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AJ55SDCAP TRIMMER 1.5-55PF 125V SMD |
1,953 |
|
Datasheet |
A | Bulk | Active | 1.5 ~ 55pF | Side | Polytetrafluoroethylene (PTFE) | - | 0.300" Dia (7.62mm) | 125 V | 1.000" (25.40mm) | -65°C ~ 125°C | Surface Mount | General Purpose |
|
|
AP55SDCAP TRIMMER 1.5-55PF 125V SMD |
1,762 |
|
Datasheet |
A | Bulk | Active | 1.5 ~ 55pF | Side | Polytetrafluoroethylene (PTFE) | 2000 @ 100MHz | 0.220" Dia (5.59mm) | 125 V | 1.000" (25.40mm) | -65°C ~ 125°C | Surface Mount | General Purpose |
|
|
AT55SDCAP TRIMMER 1.5-55PF 125V PNL MT |
1,953 |
|
Datasheet |
A | Bulk | Active | 1.5 ~ 55pF | Top | Polytetrafluoroethylene (PTFE) | 780 @ 100MHz | 0.300" Dia (7.62mm) | 125 V | 0.980" (24.89mm) | -65°C ~ 125°C | Panel Mount | General Purpose |
|
|
5640CAP FILM TRIM |
3,480 |
|
Datasheet |
- | Bulk | Active | 1 ~ 30pF | Top | Air | 800 @ 100MHz | 0.280" Dia (7.11mm) | 250 V | 0.680" (17.27mm) | -65°C ~ 125°C | Surface Mount | Non-Magnetic |
|
5642CAP FILM TRIM |
2,540 |
|
Datasheet |
- | Bulk | Active | 1 ~ 30pF | Top | Air | 800 @ 100MHz | 0.280" Dia (7.11mm) | 250 V | 0.680" (17.27mm) | -65°C ~ 125°C | Surface Mount | Non-Magnetic |
|
5641CAP FILM TRIM |
1,260 |
|
Datasheet |
- | Bulk | Active | 1 ~ 30pF | Top | Air | 800 @ 100MHz | 0.295" Dia (7.49mm) | 250 V | 0.760" (19.30mm) | -65°C ~ 125°C | Surface Mount | Non-Magnetic |
|
|
NMA4M3CAP FILM TRIM |
1,683 |
|
Datasheet |
NMA | Bulk | Active | 0.45 ~ 3pF | Side | - | 3000 @ 100MHz | - | 125 V | - | -65°C ~ 125°C | Through Hole | Non-Magnetic |
|
|
NMA4P3CAP FILM TRIM |
3,633 |
|
Datasheet |
NMA | Bulk | Active | 0.45 ~ 3pF | Side | - | 3000 @ 100MHz | - | 125 V | - | -65°C ~ 125°C | Through Hole | Non-Magnetic |
|
|
NMA4W3CAP FILM TRIM |
4,115 |
|
Datasheet |
NMA | Bulk | Active | 0.45 ~ 3pF | Side | - | 3000 @ 100MHz | - | 125 V | - | -65°C ~ 125°C | Through Hole | Non-Magnetic |
|
|
NMA4J3CAP FILM TRIM |
4,680 |
|
Datasheet |
NMA | Bulk | Active | 0.45 ~ 3pF | Side | - | 3000 @ 100MHz | 0.160" Dia (4.06mm) | 125 V | 0.225" (5.72mm) | -65°C ~ 125°C | Through Hole | General Purpose |
|
|
NMA4M5CAP FILM TRIM |
2,055 |
|
Datasheet |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - |
|
|
NMA4P5CAP FILM TRIM |
3,235 |
|
Datasheet |
NMA | Bulk | Active | 0.6 ~ 5pF | Side | - | 2000 @ 100MHz | 0.160" Dia (4.06mm) | 125 V | 0.325" (8.26mm) | -65°C ~ 125°C | Through Hole | General Purpose |
|
|
NMA4J5CAP FILM TRIM |
1,010 |
|
Datasheet |
NMA | Bulk | Active | 0.6 ~ 5pF | Side | - | 2000 @ 100MHz | - | 125 V | - | -65°C ~ 125°C | Through Hole | Non-Magnetic |
|
|
5762CAP FILM TRIM |
2,345 |
|
Datasheet |
- | Bulk | Active | 0.6 ~ 6pF | Top | Air | 10000 @ 100MHz | 0.235" Dia (5.97mm) | 250 V | 0.270" (6.86mm) | -65°C ~ 125°C | Surface Mount | Non-Magnetic |
|
|
5760CAP FILM TRIM |
3,696 |
|
Datasheet |
- | Bulk | Active | 0.6 ~ 6pF | Top | Air | 10000 @ 100MHz | 0.235" Dia (5.97mm) | 250 V | 0.270" (6.86mm) | -65°C ~ 125°C | Surface Mount | Non-Magnetic |
|
|
56H01CAP FILM TRIM |
2,447 |
|
Datasheet |
- | Bulk | Active | 2 ~ 30pF | Top | - | 1000 @ 175MHz | 0.295" Dia (7.49mm) | 1000 V | 0.580" (14.73mm) | -65°C ~ 125°C | Surface Mount | Non-Magnetic |
|
|
59H18CAP FILM TRIM |
4,148 |
|
Datasheet |
- | Bulk | Active | 1 ~ 25pF | Top | - | 1000 @ 175MHz | 0.280" Dia (7.11mm) | 1000 V | 0.641" (16.28mm) | -65°C ~ 125°C | Surface Mount | Non-Magnetic |
|
|
NMA1T4CAP FILM TRIM |
4,399 |
|
Datasheet |
NMA | Bulk | Active | 0.45 ~ 4pF | Side | - | 4000 @ 100MHz | 0.156" Dia (3.96mm) | 250 V | 0.390" (9.91mm) | -65°C ~ 125°C | Panel Mount | General Purpose |
|
|
NMA1P4CAP FILM TRIM |
4,553 |
|
Datasheet |
NMA | Bulk | Active | 0.45 ~ 4pF | Side | - | 4000 @ 100MHz | 0.160" Dia (4.06mm) | 250 V | 0.400" (10.16mm) | -65°C ~ 125°C | Through Hole | General Purpose |
|
|
NMA1J4CAP FILM TRIM |
4,568 |
|
Datasheet |
NMA | Bulk | Active | 0.45 ~ 4pF | Side | - | 4000 @ 100MHz | - | 250 V | - | -65°C ~ 125°C | Through Hole | General Purpose |
