| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Part Status | Circuit | Number of Positions | Voltage Rating | Actuator Type | Actuator Level | Current Rating (Amps) | Contact Material | Contact Finish | Height Above Board | Mounting Style | Termination Style | Operating Temperature | Pitch | Features | Washable |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RDMBC16R2TSW ROTARY DIP HEX COMP 0.1A 42V |
2,337 |
|
Datasheet |
RDM | Tube | Active | Hexadecimal Complement | 16 | 42VDC | Rotary with Shaft | Raised | 100mA | - | Gold | 0.291" (7.39mm) | Through Hole, Right Angle | PC Pin | -60°C ~ 125°C | 0.100" (2.54mm), Full | IP67 - Dust Tight, Waterproof | Yes |
|
|
CRD10RM0SKRSWITCH ROTARY DIP BCD 0.4VA 20V |
2,352 |
|
Datasheet |
CRD | Tape & Reel (TR) | Obsolete | BCD | 10 | 20VAC/DC | Rotary for Tool | Flush, Recessed | 0.4VA | Beryllium Copper | Gold | 0.271" (6.88mm) | Surface Mount | Gull Wing | -20°C ~ 85°C | 0.100" (2.54mm), Full | Process Sealed | Yes |
|
|
DRD10CESW ROTARY DIP BCD COMP 0.4VA 20V |
3,752 |
|
Datasheet |
DRD | Tube | Obsolete | BCD Complement | 10 | 20VAC/DC | Rotary for Tool | Flush, Recessed | 0.4VA | Copper Alloy | Gold | 0.256" (6.50mm) | Through Hole | PC Pin | -30°C ~ 85°C | 0.100" (2.54mm), Full | - | Yes |
|
|
DRD10SWITCH ROTARY DIP BCD 0.4VA 20V |
2,701 |
|
Datasheet |
DRD | Tube | Obsolete | BCD | 10 | 20VAC/DC | Rotary for Tool | Flush, Recessed | 0.4VA | Copper Alloy | Gold | 0.256" (6.50mm) | Through Hole | PC Pin | -30°C ~ 85°C | 0.100" (2.54mm), Full | - | No |
|
418317170912SWITCH PIANO DIP SPST 0.025A 24V |
1,250 |
|
Datasheet |
WS-DITU | Tube | Obsolete | SPST | 12 | 24VDC | Piano | Flush, Recessed | 25mA | - | Gold | 0.272" (6.90mm) | Through Hole, Right Angle | PC Pin | -40°C ~ 85°C | 0.100" (2.54mm), Full | - | No |
|
|
90B04SLTSWITCH SLIDE DIP SPST 0.025A 24V |
1,150 |
|
Datasheet |
90B | Tube | Active | SPST | 4 | 24VDC | Slide (Standard) | Flush, Recessed | 25mA | Copper Alloy | Gold | 0.195" (4.95mm) | Through Hole | PC Pin | -40°C ~ 85°C | 0.100" (2.54mm), Full | Position Identification Line, Tape Seal | Yes |
|
|
435166-1SW ROCKER DIP SPST 0.025A 24V |
4,999 |
|
Datasheet |
7000 | Tube | Obsolete | SPST | 7 | 24VDC | Rocker | Raised | 25mA | Copper Alloy | Gold | 0.340" (8.64mm) | Through Hole | PC Pin | -55°C ~ 105°C | 0.100" (2.54mm), Full | - | No |
|
|
90HGBW06RTSWITCH SLIDE DIP SPST 0.01A 30V |
4,544 |
|
Datasheet |
90HGB | Tape & Reel (TR) | Obsolete | SPST | 6 | 30VDC | Slide (Standard) | Flush, Recessed | 10mA | Copper Alloy | Gold | 0.190" (4.83mm) | Surface Mount | Gull Wing | -40°C ~ 85°C | 0.100" (2.54mm), Full | - | No |
|
90HBJ04PRTSWITCH SLIDE DIP SPST 0.025A 24V |
2,723 |
|
Datasheet |
90HB | Tape & Reel (TR) | Active | SPST | 4 | 24VDC | Slide (Standard) | Flush, Recessed | 25mA | Copper Alloy | Gold | 0.220" (5.59mm) | Surface Mount | J Lead | -40°C ~ 85°C | 0.100" (2.54mm), Full | Tape Seal | Yes |
|
|
2-5435802-1SWITCH PIANO DIP SPST |
2,983 |
|
Datasheet |
7000 | Tube | Active | SPST | 11 | - | Piano | Raised | - | - | - | - | Through Hole | - | - | - | - | Yes |
|
|
CHS-10MASWITCH SLIDE DIP SPST 0.1A 6V |
1,749 |
|
Datasheet |
CHS | Tube | Active | SPST | 10 | 6VDC | Slide (Standard) | Flush, Recessed | 100mA | Copper Alloy | Gold | 0.098" (2.50mm) | Surface Mount | J Lead | -40°C ~ 85°C | 0.050" (1.27mm), Half | - | Yes |
|
|
CHS-10MBSWITCH SLIDE DIP SPST 0.1A 6V |
2,796 |
|
Datasheet |
CHS | Tube | Active | SPST | 10 | 6VDC | Slide (Standard) | Flush, Recessed | 100mA | Copper Alloy | Gold | 0.098" (2.50mm) | Surface Mount | Gull Wing | -40°C ~ 85°C | 0.050" (1.27mm), Half | - | Yes |
|
SD-2111SWITCH ROTARY DIP BCD 0.1A 5V |
3,735 |
|
Datasheet |
SD-2000 | Bulk | Active | BCD | 10 | 5VDC | Rotary with Shaft | Raised | 100mA | Copper Alloy | Gold | 0.394" (10.00mm) | Through Hole, Right Angle | PC Pin | -40°C ~ 85°C | 0.100" (2.54mm), Full | - | No |
|
|
CVS-08BSWITCH SLIDE DIP SPST 0.1A 6V |
1,287 |
|
Datasheet |
CVS | Bulk | Active | SPST | 8 | 6VDC | Slide (Standard) | Raised | 100mA | Stainless Steel | Gold | 0.057" (1.45mm) | Surface Mount | Gull Wing | -40°C ~ 85°C | 0.039" (1.00mm) | - | No |
|
|
DRD10ESWITCH ROTARY DIP BCD 0.4VA 20V |
2,230 |
|
Datasheet |
DRD | Tube | Obsolete | BCD | 10 | 20VAC/DC | Rotary for Tool | Flush, Recessed | 0.4VA | Copper Alloy | Gold | 0.256" (6.50mm) | Through Hole | PC Pin | -30°C ~ 85°C | 0.100" (2.54mm), Full | - | Yes |
|
|
94HFB16JRTSWITCH ROTARY DIP HEX 0.1A 50V |
2,289 |
|
Datasheet |
94H | Tape & Reel (TR) | Active | Hexadecimal | 16 | 50VDC | Rotary for Tool | Flush, Recessed | 100mA | Copper Alloy | Gold | 0.250" (6.35mm) | Surface Mount | J Lead | -40°C ~ 85°C | 0.100" (2.54mm), Full | Sealed | Yes |
|
|
94HFB16WRTSWITCH ROTARY DIP HEX 0.1A 50V |
3,757 |
|
Datasheet |
94H | Tape & Reel (TR) | Active | Hexadecimal | 16 | 50VDC | Rotary for Tool | Flush, Recessed | 100mA | Copper Alloy | Gold | 0.225" (5.72mm) | Surface Mount | Gull Wing | -40°C ~ 85°C | 0.100" (2.54mm), Full | Sealed | Yes |
|
|
94HAC08WRTSW ROTARY DIP OCT COMP 0.1A 50V |
2,920 |
|
Datasheet |
94H | Tape & Reel (TR) | Active | Octal Complement | 8 | 50VDC | Rotary for Tool | Flush, Recessed | 100mA | Copper Alloy | Gold | 0.225" (5.72mm) | Surface Mount | Gull Wing | -40°C ~ 85°C | 0.100" (2.54mm), Full | Sealed | Yes |
|
|
94HAC10WRTSW ROTARY DIP BCD COMP 0.1A 50V |
2,327 |
|
Datasheet |
94H | Tape & Reel (TR) | Active | BCD Complement | 10 | 50VDC | Rotary for Tool | Flush, Recessed | 100mA | Copper Alloy | Gold | 0.225" (5.72mm) | Surface Mount | Gull Wing | -40°C ~ 85°C | 0.100" (2.54mm), Full | Sealed | Yes |
|
|
94HAC16WRTSW ROTARY DIP HEX COMP 0.1A 50V |
1,876 |
|
Datasheet |
94H | Tape & Reel (TR) | Active | Hexadecimal Complement | 16 | 50VDC | Rotary for Tool | Flush, Recessed | 100mA | Copper Alloy | Gold | 0.225" (5.72mm) | Surface Mount | Gull Wing | -40°C ~ 85°C | 0.100" (2.54mm), Full | Sealed | Yes |
