| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Part Status | Type | Material - Core | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Inductance | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Mounting Style | Operating Temperature | Features | Inductance Frequency - Test | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CIH05T82NJNCFIXED IND 82NH 100MA 1.6 OHM SMD |
3,653 |
|
Datasheet |
CIH05T | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±5% | 100 mA | - | 82 nH | Unshielded | 1.6Ohm Max | 8 @ 100MHz | 600MHz | - | Surface Mount | -55°C ~ 125°C | - | 100 MHz | - | 0.039" L x 0.020" W (1.00mm x 0.50mm) | - |
|
|
CIH05T3N3SNCFIXED IND 3.3NH 300MA 190MOHM SM |
3,259 |
|
Datasheet |
CIH05T | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±0.3nH | 300 mA | - | 3.3 nH | Unshielded | 190mOhm Max | 8 @ 100MHz | 6GHz | - | Surface Mount | -55°C ~ 125°C | - | 100 MHz | - | 0.039" L x 0.020" W (1.00mm x 0.50mm) | - |
|
CIH10T1N0SNCFIXED IND 1NH 800MA 50 MOHM SMD |
4,334 |
|
Datasheet |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±0.3nH | 800 mA | - | 1 nH | Unshielded | 50mOhm Max | 8 @ 100MHz | 10GHz | - | Surface Mount | -55°C ~ 125°C | - | 100 MHz | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - |
|
|
CIH10T1N5SNCFIXED IND 1.5NH 800MA 100MOHM SM |
2,894 |
|
Datasheet |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±0.3nH | 800 mA | - | 1.5 nH | Unshielded | 100mOhm Max | 8 @ 100MHz | 6GHz | - | Surface Mount | -55°C ~ 125°C | - | 100 MHz | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - |
|
|
CIH10T3N9SNCFIXED IND 3.9NH 800MA 140MOHM SM |
4,471 |
|
Datasheet |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±0.3nH | 800 mA | - | 3.9 nH | Unshielded | 140mOhm Max | 10 @ 100MHz | 6GHz | - | Surface Mount | -55°C ~ 125°C | - | 100 MHz | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - |
|
|
CIH10T5N6SNCFIXED IND 5.6NH 800MA 180MOHM SM |
4,671 |
|
Datasheet |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±0.3nH | 800 mA | - | 5.6 nH | Unshielded | 180mOhm Max | 10 @ 100MHz | 4GHz | - | Surface Mount | -55°C ~ 125°C | - | 100 MHz | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - |
|
|
CIH10T10NJNCFIXED IND 10NH 600MA 260MOHM SMD |
4,941 |
|
Datasheet |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±5% | 600 mA | - | 10 nH | Unshielded | 260mOhm Max | 12 @ 100MHz | 3.4GHz | - | Surface Mount | -55°C ~ 125°C | - | 100 MHz | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - |
|
|
CIH10T12NJNCFIXED IND 12NH 600MA 280MOHM SMD |
1,696 |
|
Datasheet |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±5% | 600 mA | - | 12 nH | Unshielded | 280mOhm Max | 12 @ 100MHz | 2.6GHz | - | Surface Mount | -55°C ~ 125°C | - | 100 MHz | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - |
|
|
CIH10T15NJNCFIXED IND 15NH 500MA 320MOHM SMD |
4,655 |
|
Datasheet |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±5% | 500 mA | - | 15 nH | Unshielded | 320mOhm Max | 12 @ 100MHz | 2.3GHz | - | Surface Mount | -55°C ~ 125°C | - | 100 MHz | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - |
|
|
CIH10T18NJNCFIXED IND 18NH 500MA 350MOHM SMD |
1,190 |
|
Datasheet |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±5% | 500 mA | - | 18 nH | Unshielded | 350mOhm Max | 12 @ 100MHz | 2GHz | - | Surface Mount | -55°C ~ 125°C | - | 100 MHz | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - |
|
|
CIH10T22NJNCFIXED IND 22NH 500MA 400MOHM SMD |
2,984 |
|
Datasheet |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±5% | 500 mA | - | 22 nH | Unshielded | 400mOhm Max | 12 @ 100MHz | 1.6GHz | - | Surface Mount | -55°C ~ 125°C | - | 100 MHz | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - |
|
|
CIH10T27NJNCFIXED IND 27NH 500MA 450MOHM SMD |
2,353 |
|
Datasheet |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±5% | 500 mA | - | 27 nH | Unshielded | 450mOhm Max | 12 @ 100MHz | 1.4GHz | - | Surface Mount | -55°C ~ 125°C | - | 100 MHz | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - |
|
|
CIH10T47NJNCFIXED IND 47NH 400MA 770MOHM SMD |
1,810 |
|
Datasheet |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±5% | 400 mA | - | 47 nH | Unshielded | 770mOhm Max | 12 @ 100MHz | 900MHz | - | Surface Mount | -55°C ~ 125°C | - | 100 MHz | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - |
|
|
CIH10T68NJNCFIXED IND 68NH 350MA 850MOHM SMD |
4,994 |
|
Datasheet |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±5% | 350 mA | - | 68 nH | Unshielded | 850mOhm Max | 12 @ 100MHz | 700MHz | - | Surface Mount | -55°C ~ 125°C | - | 100 MHz | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - |
|
|
CIH10T82NJNCFIXED IND 82NH 350MA 950MOHM SMD |
2,540 |
|
Datasheet |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±5% | 350 mA | - | 82 nH | Unshielded | 950mOhm Max | 12 @ 100MHz | 600MHz | - | Surface Mount | -55°C ~ 125°C | - | 100 MHz | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - |
|
|
CIH10TR10JNCFIXED IND 100NH 350MA 1 OHM SMD |
4,718 |
|
Datasheet |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±5% | 350 mA | - | 100 nH | Unshielded | 1Ohm Max | 12 @ 100MHz | 600MHz | - | Surface Mount | -55°C ~ 125°C | - | 100 MHz | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - |
|
0412CDMCBDS-1R0MCFIXED IND 1UH 4.5A 40 MOHM SMD |
2,972 |
|
Datasheet |
0412CDMCB/DS | 2-SMD | Tape & Reel (TR) | Obsolete | Wirewound | - | ±20% | 4.5 A | 5.3A | 1 µH | Shielded | 40mOhm | - | - | - | Surface Mount | -40°C ~ 105°C | - | 100 kHz | SMD | 0.177" L x 0.161" W (4.50mm x 4.10mm) | 0.047" (1.20mm) |
|
0410CDMCBDS-1R5MCFIXED IND 1.5UH 3.4A 66 MOHM SMD |
3,705 |
|
Datasheet |
0410CDMCB/DS | 2-SMD | Tape & Reel (TR) | Obsolete | Wirewound | - | ±20% | 3.4 A | 2.5A | 1.5 µH | Shielded | 66mOhm | - | - | - | Surface Mount | -40°C ~ 105°C | - | 100 kHz | SMD | 0.177" L x 0.161" W (4.50mm x 4.10mm) | 0.047" (1.20mm) |
|
0420CDMCBDS-R22MCFIXED IND 220NH 10.1A 5.3MOHM SM |
4,610 |
|
Datasheet |
0420CDMCB/DS | 2-SMD | Tape & Reel (TR) | Obsolete | Wirewound | - | ±20% | 10.1 A | 15A | 220 nH | Shielded | 5.3mOhm | - | - | - | Surface Mount | -40°C ~ 105°C | - | 100 kHz | SMD | 0.177" L x 0.161" W (4.50mm x 4.10mm) | 0.079" (2.00mm) |
|
|
0420CDMCBDS-220MCFIXED IND 22UH 1.3A 316 MOHM SMD |
2,936 |
|
Datasheet |
0420CDMCB/DS | 2-SMD | Tape & Reel (TR) | Obsolete | Wirewound | - | ±20% | 1.3 A | 1.6A | 22 µH | Shielded | 316mOhm | - | - | - | Surface Mount | -40°C ~ 105°C | - | 100 kHz | SMD | 0.177" L x 0.161" W (4.50mm x 4.10mm) | 0.079" (2.00mm) |
