Keylock Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Part Status | Circuit | Number of Positions | Contact Timing | Current Rating (Amps) | Voltage Rating - AC | Switch Function | Voltage Rating - DC | Actuator Type | Key Removable Positions | Angle of Throw | Contact Material | Panel Cutout Dimensions | Contact Finish | Termination Style | Mounting Style | Features | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
M22K-30SF11-BSWITCH KEYLOCK 3POS SPST 6A 230V |
750 |
|
Datasheet |
M22 | Bulk | Active | SPST | 3 | - | 6A (AC), 3A (DC) | 230 V | - | 24 V | Flat Key | All | 45° | Silver-Nickel Alloy | Circular - 22.30mm Dia | Silver | Screw Terminal | - | - | - |
|
M22K-22SB02-ASWITCH KEYLOCK 2POS DPST 6A 230V |
750 |
|
Datasheet |
M22 | Bulk | Active | DPST | 2 | - | 6A (AC), 3A (DC) | 230 V | - | 24 V | Flat Key | Center | 45° | Silver-Nickel Alloy | Circular - 22.30mm Dia | Silver | Screw Terminal | - | - | - |
|
KSL30WK2-1130mm KEY SELECTOR SWITCH |
2,000 |
|
Datasheet |
K | Bulk | Active | DPST-NO/NC | 2 | Not Specified | 6A (AC), 3A (DC) | 250 V | On-Off, Off-On | 125 V | Flat Key | All | 90° | Copper Silver Alloy | Circular - 25.00mm Dia | - | Screw Terminal | Panel Mount | IP65 | -25°C ~ 50°C |
|
|
KSL25WK2-1125mm SELECTOR SWITCH |
2,000 |
|
Datasheet |
K | Bulk | Active | DPST-NO/NC | 2 | - | 6A (AC), 3A (DC) | 250 V | On-Off, Off-On | 125 V | Flat Key | All | 90° | - | Circular - 25.00mm Dia | - | Screw Terminal | Panel Mount | IP65 | -25°C ~ 50°C |
|
|
KSL30WAK3-1130mm KEY SELECTOR SWITCH |
2,000 |
|
Datasheet |
K | Bulk | Active | DPST-NO/NC | 3 | Not Specified | 6A (AC), 3A (DC) | 250 V | On-Mom, Off-Mom | 125 V | Flat Key | All | 45° | Copper Silver Alloy | Circular - 25.00mm Dia | - | Screw Terminal | Panel Mount | IP65 | -25°C ~ 50°C |
|
|
KSL25WAK3-1125mm SELECTOR SWITCH |
2,000 |
|
Datasheet |
K | Bulk | Active | DPST-NO/NC | 3 | - | 6A (AC), 3A (DC) | 250 V | On-Mom, Off-Mom | 125 V | Flat Key | All | 45° | - | Circular - 25.00mm Dia | - | Screw Terminal | Panel Mount | IP65 | -25°C ~ 50°C |
|
|
KSL25WK3-1125mm SELECTOR SWITCH |
2,000 |
|
Datasheet |
K | Bulk | Active | DPST-NO/NC | 3 | - | 6A (AC), 3A (DC) | 250 V | On-Off, Off-On | 125 V | Flat Key | All | 45° | - | Circular - 25.00mm Dia | - | Screw Terminal | Panel Mount | IP65 | -25°C ~ 50°C |
|
|
KSL30WK3-1130mm KEY SELECTOR SWITCH |
2,000 |
|
Datasheet |
K | Bulk | Active | DPST-NO/NC | 3 | Not Specified | 6A (AC), 3A (DC) | 250 V | On-Off, Off-On | 125 V | Flat Key | All | 45° | Copper Silver Alloy | Circular - 25.00mm Dia | - | Screw Terminal | Panel Mount | IP65 | -25°C ~ 50°C |
|
|
KSL30WAK2-1130mm KEY SELECTOR SWITCH |
2,000 |
|
Datasheet |
K | Bulk | Active | DPST-NO/NC | 2 | Not Specified | 6A (AC), 3A (DC) | 250 V | On-Mom, Off-Mom | 125 V | Flat Key | All | 90° | Copper Silver Alloy | Circular - 25.00mm Dia | - | Screw Terminal | Panel Mount | IP65 | -25°C ~ 50°C |
|
|
KSL25WAK2-1125mm SELECTOR SWITCH |
2,000 |
|
Datasheet |
K | Bulk | Active | DPST-NO/NC | 2 | - | 6A (AC), 3A (DC) | 250 V | On-Mom, Off-Mom | 125 V | Flat Key | All | 90° | - | Circular - 25.00mm Dia | - | Screw Terminal | Panel Mount | IP65 | -25°C ~ 50°C |
|
|
1-1437597-12SKF231AEL01=NON UL KEYLOCK |
1,410 |
|
Datasheet |
SKF | Box | Active | SPST | 2 | Non-Shorting (BBM) | 1A (AC) | 120 V | Off-Mom | - | Flat Key | 1 only | 90° | Silver (Ag) | Circular - 19.20mm Dia | - | Screw Terminal | Panel Mount | - | -30°C ~ 85°C |
|
SK12BAW01SWITCH KEYLOCK 2POS SPDT 3A 125V |
4,155 |
|
Datasheet |
SK | Bulk | Active | SPDT | 2 | Non-Shorting (BBM) | 3A (AC) | 125 V | On-On | - | Flat Key | 1 only | 90° | Silver (Ag) | Circular - 12.00mm Dia | - | Solder Lug | Panel Mount | Epoxy Sealed Terminals | -25°C ~ 70°C |
|
3SU11504BF013PA0SWITCH KEYLCK 2POS DPST 10A 500V |
4,984 |
|
Datasheet |
3SU1 | Bulk | Active | DPST-NC | 2 | Not Specified | 10A (AC/DC) | 500 V | On-Off | 500 V | Flat Key | Left | 90° | Silver Alloy | Circular - 22.30mm Dia | Silver | Spring Terminal | Panel Mount | - | -25°C ~ 70°C |
|
A22TK-2LL-02-K01SWITCH KEYLCK 2POS DPST 10A 110V |
1,416 |
|
Datasheet |
A22TK | Box | Active | DPST-NC | 2 | Not Specified | 10A (AC/DC) | 110 V | On-Off | 24 V | Tubular Key | Left | 90° | - | Circular - 22.30mm Dia | - | Screw Terminal | Panel Mount | IP65 | -20°C ~ 70°C |
|
SW-R-K5-ASWITCH KEYLOCK 2POS SPST 1A 125V |
4,285 |
|
Datasheet |
SW | Bag | Active | SPST | 2 | Not Specified | 1A (AC) | 125 V | Off-On | - | Flat Key | All | 90° | - | Circular - 11.80mm Dia | - | Solder Lug | Panel Mount | - | -25°C ~ 85°C |
|
CKM12AFW01SWITCH KEYLOCK 2POS SPDT 3A 250V |
4,116 |
|
Datasheet |
CK | Bulk | Active | SPDT | 2 | Non-Shorting (BBM) | 3A (AC) | 250 V | On-On | - | Flat Key | All | 90° | Silver (Ag) | Circular - 16.00mm Dia | Silver | Solder Lug | Panel Mount | Epoxy Sealed Terminals | -25°C ~ 70°C |
|
SK12AG30SWITCH KEYLK 2POS SPDT 0.4VA 28V |
1,260 |
|
Datasheet |
SK | Bulk | Active | SPDT | 2 | Non-Shorting (BBM) | 0.4VA (AC/DC) | 28 V | On-On | 28 V | Flat Key | All | 90° | Beryllium Copper | - | Gold | PC Pin | Through Hole, Right Angle | Process Sealed | -25°C ~ 70°C |
|
|
SK13EAW01SWITCH KEYLOCK 3POS SPDT 3A 125V |
1,841 |
|
Datasheet |
SK | Bulk | Active | SPDT | 3 | Non-Shorting (BBM) | 3A (AC) | 125 V | On-Off-On | - | Flat Key | 2 only | 45° | Silver (Ag) | Circular - 12.00mm Dia | - | Solder Lug | Panel Mount | Epoxy Sealed Terminals | -25°C ~ 70°C |
|
|
PVK4K21A0SSSWITCH KEYLOCK 2POS SPDT 2A 24V |
4,097 |
|
Datasheet |
PVK4 | Box | Active | SPDT | 2 | Not Specified | 2A (DC) | - | On-On | 24 V | Flat Key | All | 90° | Silver (Ag) | Circular - 19.00mm Dia | - | Solder Lug | Panel Mount | - | -20°C ~ 55°C |
|
CKL12BTW01SWITCH KEYLOCK 2POS SPDT 3A 250V |
3,582 |
|
Datasheet |
CK | Bulk | Active | SPDT | 2 | Non-Shorting (BBM) | 3A (AC) | 250 V | On-On | - | Tubular Key | 1 only | 90° | Silver (Ag) | Circular - 19.00mm Dia | Silver | Solder Lug | Panel Mount | Epoxy Sealed Terminals | -25°C ~ 70°C |
