Result

Mfr. Part #	Availability	Price	Quantity	Datasheet	Series	Packaging	Part Status	Circuit	Switch Function	Voltage Rating - AC	Voltage Rating - DC	Actuator Type	Current Rating (Amps)	Mounting Style	Termination Style	Ingress Protection	Features	Operating Force	Differential Travel	Release Force	Pretravel	Operating Position	Overtravel	Operating Temperature
LS0851504F140C1C SWITCH SNAP ACT SPST-NO 15A 125V E-Switch	1,161	-	RFQ Sell Excess Inventory	Datasheet	LS	Bulk	Active	SPST-NO	Off-Mom	125 V	-	Lever, Simulated Roller	15A (AC)	Chassis Mount	Quick Connect - 0.187" (4.7mm)	-	-	140gf	-	40gf	0.205" (5.2mm)	0.748" (19.0mm)	-	-25°C ~ 85°C
MBB101B01C08A SNAP ACTING SWITCH MB APEM Inc.	2,582	-	RFQ Sell Excess Inventory	Datasheet	MBB	Bulk	Active	SPDT	On-Mom	125 V	-	Lever, Straight	5A (AC)	Chassis Mount	Quick Connect - 0.250" (6.3mm)	-	-	153gf	0.031" (0.80mm)	46gf	0.165" (4.2mm)	0.386" (9.8mm)	0.039" (1.0mm)	0°C ~ 85°C
AV32029 SWITCH SNAP ACTION SPDT 3A 125V Panasonic Electric Works	4,428	-	RFQ Sell Excess Inventory	Datasheet	AV3	Bulk	Active	SPDT	On-Mom	125 V	30 V	Round (Pin Plunger)	3A (AC/DC)	Chassis Mount	Solder Lug	-	-	50gf	0.004" (0.1mm)	7.546gf	0.024" (0.6mm)	0.330" (8.4mm)	0.015" (0.4mm)	-25°C ~ 85°C
AV32049 SWITCH SNAP ACTION SPDT 3A 125V Panasonic Electric Works	1,393	-	RFQ Sell Excess Inventory	Datasheet	AV3	Bulk	Active	SPDT	On-Mom	125 V	30 V	Round (Pin Plunger)	3A (AC/DC)	Chassis Mount	Solder Lug	-	-	100gf	0.004" (0.1mm)	15gf	0.024" (0.6mm)	0.330" (8.4mm)	0.015" (0.4mm)	-25°C ~ 85°C
AVT32049 SWITCH SNAP ACTION SPDT 3A 125V Panasonic Electric Works	4,682	-	RFQ Sell Excess Inventory	Datasheet	AVT3	Tube	Active	SPDT	On-Mom	125 V	30 V	Round (Pin Plunger)	3A (AC/DC)	Chassis Mount	Solder Lug	-	-	100gf	0.004" (0.1mm)	15gf	0.024" (0.6mm)	0.330" (8.4mm)	0.015" (0.4mm)	-25°C ~ 85°C
AVT34049 SWITCH SNAP ACTION SPDT 3A 125V Panasonic Electric Works	2,230	-	RFQ Sell Excess Inventory	Datasheet	AVT3	Bulk	Active	SPDT	On-Mom	125 V	30 V	Round (Pin Plunger)	3A (AC/DC)	Through Hole	PC Pin	-	-	100gf	0.004" (0.1mm)	15gf	0.024" (0.6mm)	0.330" (8.4mm)	0.015" (0.4mm)	-25°C ~ 85°C
AVT38029 SWITCH SNAP ACTION SPDT 3A 125V Panasonic Electric Works	4,107	-	RFQ Sell Excess Inventory	Datasheet	AVT3	Bulk	Active	SPDT	On-Mom	125 V	30 V	Round (Pin Plunger)	3A (AC/DC)	Chassis Mount	Quick Connect - 0.110" (2.8mm)	-	-	50gf	0.004" (0.1mm)	7.546gf	0.024" (0.6mm)	0.330" (8.4mm)	0.015" (0.4mm)	-25°C ~ 85°C
AVT38049 SWITCH SNAP ACTION SPDT 3A 125V Panasonic Electric Works	4,843	-	RFQ Sell Excess Inventory	Datasheet	AVT3	Bulk	Active	SPDT	On-Mom	125 V	30 V	Round (Pin Plunger)	3A (AC/DC)	Chassis Mount	Quick Connect - 0.110" (2.8mm)	-	-	100gf	0.004" (0.1mm)	15gf	0.024" (0.6mm)	0.330" (8.4mm)	0.015" (0.4mm)	-25°C ~ 85°C
ZX40C20A01 SWITCH SNAP ACTION SPDT 3A 125V Honeywell Sensing and Productivity Solutions	2,898	-	RFQ Sell Excess Inventory	Datasheet	ZX	Box	Obsolete	SPDT	On-Mom	125 V	-	Round (Pin Plunger)	3A (AC)	Through Hole	PC Pin	IP40	-	90gf	0.012" (0.3mm)	15gf	0.012" (0.3mm)	0.276" (7.0mm)	0.008" (0.2mm)	-40°C ~ 85°C
ZMA00A150L21LC SWITCH SNAP ACT SPDT 0.1A 125V C&K	2,958	-	RFQ Sell Excess Inventory	Datasheet	ZMA	Bulk	Active	SPDT	On-Mom	125 V	60 V	Lever, Straight	100mA (AC/DC)	Through Hole	PC Pin	-	-	47gf	-	7.000gf	0.094" (2.4mm)	0.330" (8.4mm)	0.025" (0.6mm)	-40°C ~ 85°C
SM3AQF1303L00 SWITCH LIMIT SPST-NO 5A 125V CIT Relay and Switch	1,099	-	RFQ Sell Excess Inventory	Datasheet	SM3	Bag	Active	SPST-NO	Off-Mom	125 V	-	Round (Pin Plunger)	5A (AC)	Through Hole	PC Pin	-	-	130gf	0.002" (0.05mm)	75gf	0.041" (1.05mm)	0.413" (10.5mm)	0.015" (0.4mm)	-40°C ~ 120°C
SM3AQF1301L00 SWITCH LIMIT SPST-NO 5A 125V CIT Relay and Switch	3,622	-	RFQ Sell Excess Inventory	Datasheet	SM3	Bag	Active	SPST-NO	Off-Mom	125 V	-	Round (Pin Plunger)	5A (AC)	Chassis Mount	Quick Connect - 0.110" (2.8mm)	-	-	130gf	0.002" (0.05mm)	75gf	0.041" (1.05mm)	0.413" (10.5mm)	0.015" (0.4mm)	-40°C ~ 120°C
SM3AQF1302L04 SWITCH LIMIT SPST-NO 5A 125V CIT Relay and Switch	1,811	-	RFQ Sell Excess Inventory	Datasheet	SM3	Bag	Active	SPST-NO	Off-Mom	125 V	-	Lever, Straight	5A (AC)	Chassis Mount	Solder Lug	-	-	25gf	0.047" (1.2mm)	10gf	0.256" (6.5mm)	0.413" (10.5mm)	0.059" (1.5mm)	-40°C ~ 120°C
ZMAG00150L08RC SWITCH SNAP ACT SPDT 0.1A 125V C&K	1,190	-	RFQ Sell Excess Inventory	Datasheet	ZMA	Bulk	Active	SPDT	On-Mom	125 V	60 V	Lever, Straight	100mA (AC/DC)	Through Hole, Right Angle	PC Pin	-	-	48gf	-	8.000gf	0.138" (3.5mm)	0.423" (10.75mm)	0.012" (0.3mm)	-40°C ~ 85°C
AV34023 SWITCH SNAP ACTION SPDT 3A 125V Panasonic Electric Works	3,517	-	RFQ Sell Excess Inventory	Datasheet	AV3	Bulk	Active	SPDT	On-Mom	125 V	30 V	Round (Pin Plunger)	3A (AC/DC)	Through Hole	PC Pin	-	-	50gf	0.004" (0.1mm)	7.546gf	0.024" (0.6mm)	0.331" (8.40mm)	0.015" (0.4mm)	-25°C ~ 85°C
AVT32043 SWITCH SNAP ACTION SPDT 3A 125V Panasonic Electric Works	1,017	-	RFQ Sell Excess Inventory	Datasheet	AVT3	Bulk	Active	SPDT	On-Mom	125 V	30 V	Round (Pin Plunger)	3A (AC/DC)	Chassis Mount	Solder Lug	IP40	-	100gf	0.004" (0.1mm)	15gf	0.024" (0.6mm)	0.331" (8.40mm)	0.015" (0.4mm)	-25°C ~ 85°C
AV3202 SWITCH SNAP ACTION SPDT 3A 125V Panasonic Electric Works	1,535	-	RFQ Sell Excess Inventory	Datasheet	AV3	Bulk	Active	SPDT	On-Mom	125 V	30 V	Round (Pin Plunger)	3A (AC/DC)	Chassis Mount	Solder Lug	-	-	50gf	0.004" (0.1mm)	7.546gf	0.024" (0.6mm)	0.331" (8.40mm)	0.015" (0.4mm)	-25°C ~ 85°C
AVT3802 SWITCH SNAP ACTION SPDT 3A 125V Panasonic Electric Works	3,624	-	RFQ Sell Excess Inventory	Datasheet	AVT3	Bulk	Active	SPDT	On-Mom	125 V	30 V	Round (Pin Plunger)	3A (AC/DC)	Chassis Mount	Quick Connect - 0.110" (2.8mm)	IP40	-	50gf	0.004" (0.1mm)	7.546gf	0.024" (0.6mm)	0.331" (8.40mm)	0.015" (0.4mm)	-25°C ~ 85°C
AV36043 SWITCH SNAP ACTION SPDT 3A 125V Panasonic Electric Works	4,515	-	RFQ Sell Excess Inventory	Datasheet	AV3	Bulk	Active	SPDT	On-Mom	125 V	30 V	Round (Pin Plunger)	3A (AC/DC)	Through Hole, Right Angle	PC Pin	-	-	100gf	0.004" (0.1mm)	15gf	0.024" (0.6mm)	0.331" (8.40mm)	0.015" (0.4mm)	-25°C ~ 85°C
AV37023 SWITCH SNAP ACTION SPDT 3A 125V Panasonic Electric Works	2,703	-	RFQ Sell Excess Inventory	Datasheet	AV3	Bulk	Active	SPDT	On-Mom	125 V	30 V	Round (Pin Plunger)	3A (AC/DC)	Through Hole, Right Angle	PC Pin	-	-	50gf	0.004" (0.1mm)	7.546gf	0.024" (0.6mm)	0.331" (8.40mm)	0.015" (0.4mm)	-25°C ~ 85°C

Total 23871 Record«Prev 1... 407 408 409 410411412 413 414...1194 Next»
