| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Part Status | Type | Coil Type | Current Rating (Amps) | Steps per Revolution | Step Angle | Voltage - Rated | Accuracy | Torque - Holding (oz-in / mNm) | Size / Dimension | NEMA Frame Size | Diameter - Shaft | Operating Temperature | Length - Shaft and Bearing | Termination Style | Mounting Hole Spacing | Coil Resistance | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
17PY-Z845-99VSSTEP MOTOR HYBRID DUAL SHAFT 24V |
3,347 |
|
Datasheet |
17PY | Bulk | Active | Hybrid, Dual Shaft | Unipolar | 1.2 A | 400.0 | 0.9° | 24VDC | ±5% | 36.82 / 260 | Square - 1.654" x 1.654" (42.00mm x 42.00mm) | 17 | 0.197" (5.00mm) | -10°C ~ 50°C | 0.787" (20.00mm) | Wire Leads with Connector | 1.220" (31.00mm) | 2.9 Ohms | Flatted Shaft |
|
17PY-Z858-99VSSTEP MOTOR HYBRID DUAL SHAFT 24V |
3,404 |
|
Datasheet |
17PY | Bulk | Active | Hybrid, Dual Shaft | Unipolar | 750 mA | 400.0 | 0.9° | 24VDC | ±5% | 36.82 / 260 | Square - 1.654" x 1.654" (42.00mm x 42.00mm) | 17 | 0.197" (5.00mm) | -10°C ~ 50°C | 0.787" (20.00mm) | Wire Leads with Connector | 1.220" (31.00mm) | 7.4 Ohms | Flatted Shaft |
|
17PM-K845-99VSSTEP MOTOR HYBRID DUAL SHAFT 24V |
1,979 |
|
Datasheet |
17PM | Bulk | Active | Hybrid, Dual Shaft | Unipolar | 1.2 A | 200.0 | 1.8° | 24VDC | ±5% | 38.24 / 270 | Square - 1.654" x 1.654" (42.00mm x 42.00mm) | 17 | 0.197" (5.00mm) | -10°C ~ 50°C | 0.984" (25.00mm) | Wire Leads | 1.220" (31.00mm) | 2.9 Ohms | Flatted Shaft |
|
17PM-K858-99VSSTEP MOTOR HYBRID DUAL SHAFT 24V |
2,684 |
|
Datasheet |
17PM | Bulk | Active | Hybrid, Dual Shaft | Unipolar | 750 mA | 200.0 | 1.8° | 24VDC | ±5% | 38.24 / 270 | Square - 1.654" x 1.654" (42.00mm x 42.00mm) | 17 | 0.197" (5.00mm) | -10°C ~ 50°C | 0.984" (25.00mm) | Wire Leads | 1.220" (31.00mm) | 7.4 Ohms | Flatted Shaft |
|
23KY-K251USTEP MOTOR HYBRID UNIPOLAR 24V |
2,481 |
|
Datasheet |
23KY | Bulk | Active | Hybrid | Unipolar | 1.8 A | 400.0 | 0.9° | 24VDC | - | 66.57 / 470 | Square - 2.220" x 2.220" (56.40mm x 56.40mm) | 23 | 0.250" (6.35mm) | - | 0.813" (20.64mm) | Connector | 1.856" (47.14mm) | 1.6 Ohms | Round Shaft |
|
WO-417-13-13STEPPER MOTOR |
3,356 |
|
Datasheet |
- | Tray | Active | - | Bipolar | 800 mA | 400.0 | 0.9° | 24VDC | - | 28.4 / 200.5 | Square - 1.650" L x 1.650" W (41.90mm x 41.90mm) | 17 | 0.197" (5.00mm) | -20°C ~ 50°C | 0.787" (20.00mm) | Wire Leads | 1.220" (31.00mm) | 13 Ohms | Round Shaft |
|
17PY-Z455-00VSSTEP MOTOR HYBRID UNIPOLAR 24V |
4,336 |
|
Datasheet |
17PY | Bulk | Active | Hybrid | Unipolar | 800 mA | 400.0 | 0.9° | 24VDC | ±5% | 46.74 / 330 | Square - 1.654" x 1.654" (42.00mm x 42.00mm) | 17 | 0.197" (5.00mm) | -10°C ~ 50°C | 0.787" (20.00mm) | Wire Leads with Connector | 1.220" (31.00mm) | 7.3 Ohms | Flatted Shaft |
|
|
23KY-K040BSTEPPER MOTOR HYBRID BIPOLAR 24V |
2,612 |
|
Datasheet |
23KY | Bulk | Active | Hybrid | Bipolar | 2.8 A | 400.0 | 0.9° | 24VDC | ±5% | 148.71 / 1050 | Square - 2.220" x 2.220" (56.40mm x 56.40mm) | 23 | 0.250" (6.35mm) | - | 0.813" (20.64mm) | Connector | 1.856" (47.14mm) | 0.9 Ohms | Round Shaft |
|
17PM-K444-00VSSTEP MOTOR HYBRID UNIPOLAR 24V |
3,052 |
|
Datasheet |
17PM | Bulk | Active | Hybrid | Unipolar | 1.2 A | 200.0 | 1.8° | 24VDC | ±5% | 48.15 / 340 | Square - 1.654" x 1.654" (42.00mm x 42.00mm) | 17 | 0.197" (5.00mm) | -10°C ~ 50°C | 0.984" (25.00mm) | Wire Leads | 1.220" (31.00mm) | 3.3 Ohms | Flatted Shaft |
|
|
23KY-K050USTEP MOTOR HYBRID UNIPOLAR 24V |
2,425 |
|
Datasheet |
23KY | Bulk | Active | Hybrid | Unipolar | 2 A | 400.0 | 0.9° | 24VDC | - | 126.05 / 890 | Square - 2.220" x 2.220" (56.40mm x 56.40mm) | 23 | 0.250" (6.35mm) | - | 0.813" (20.64mm) | Connector | 1.856" (47.14mm) | 1.8 Ohms | Round Shaft |
|
17PM-K444-99VSSTEP MOTOR HYBRID DUAL SHAFT 24V |
1,971 |
|
Datasheet |
17PM | Bulk | Active | Hybrid, Dual Shaft | Unipolar | 1.2 A | 200.0 | 1.8° | 24VDC | ±5% | 48.15 / 340 | Square - 1.654" x 1.654" (42.00mm x 42.00mm) | 17 | 0.197" (5.00mm) | -10°C ~ 50°C | 0.984" (25.00mm) | Wire Leads | 1.220" (31.00mm) | 3.3 Ohms | Flatted Shaft |
|
|
23KY-K748USTEP MOTOR HYBRID UNIPOLAR 24V |
1,582 |
|
Datasheet |
23KY | Bulk | Active | Hybrid | Unipolar | 2 A | 400.0 | 0.9° | 24VDC | - | 177.04 / 1250 | Square - 2.220" x 2.220" (56.40mm x 56.40mm) | 23 | 0.250" (6.35mm) | - | 0.813" (20.64mm) | Connector | 1.856" (47.14mm) | 2.3 Ohms | Round Shaft |
|
17PM-KA39BSTEPPER MOTOR HYBRID BIPOLAR 24V |
4,995 |
|
Datasheet |
17PM | Bulk | Active | Hybrid | Bipolar | 1 A | 200.0 | 1.8° | 24VDC | ±5% | 86.39 / 610 | Square - 1.654" x 1.654" (42.00mm x 42.00mm) | 17 | 0.197" (5.00mm) | - | 0.945" (24.00mm) | Wire Leads with Connector | 1.220" (31.00mm) | 6 Ohms | Round Shaft |
|
23KM-K267-99VSTEP MOTOR HYBRID DUAL SHAFT 24V |
3,228 |
|
Datasheet |
23KM | Bulk | Active | Hybrid, Dual Shaft | Unipolar | 900 mA | 200.0 | 1.8° | 24VDC | ±5% | 67.98 / 480 | Square - 2.220" x 2.220" (56.40mm x 56.40mm) | 23 | 0.250" (6.35mm) | -10°C ~ 50°C | 0.984" (25.00mm) | Wire Leads with Connector | 1.856" (47.14mm) | 5.8 Ohms | Flatted Shaft |
|
23KM-K244-99VSTEP MOTOR HYBRID DUAL SHAFT 24V |
4,159 |
|
Datasheet |
23KM | Bulk | Active | Hybrid, Dual Shaft | Unipolar | 2.9 A | 200.0 | 1.8° | 24VDC | ±5% | 67.98 / 480 | Square - 2.220" x 2.220" (56.40mm x 56.40mm) | 23 | 0.250" (6.35mm) | -10°C ~ 50°C | 0.984" (25.00mm) | Wire Leads with Connector | 1.856" (47.14mm) | 0.6 Ohms | Flatted Shaft |
|
SM3.4-F20-HHD9MOTORS & SOLENOIDS |
2,109 |
|
Datasheet |
SM3.4-F20 | Bulk | Active | Permanent Magnet | Bipolar | - | 20.0 | 18° | 3V | - | - | Round - 0.134" Dia (3.40mm) | - | 0.024" (0.60mm) | -10°C ~ 50°C | - | PC Pin | - | 25 Ohms | Round Shaft |
|
|
SM3.4-F20-HHD11MOTORS & SOLENOIDS |
1,071 |
|
Datasheet |
SM3.4-F20 | Bulk | Active | Permanent Magnet | Bipolar | - | 20.0 | 18° | 3V | - | - | Round - 0.134" Dia (3.40mm) | - | 0.024" (0.60mm) | -10°C ~ 50°C | - | PC Pin | - | 25 Ohms | Round Shaft |
|
|
SM3.4-F20-HHD10MOTORS & SOLENOIDS |
2,027 |
|
Datasheet |
SM3.4-F20 | Bulk | Active | Permanent Magnet | Bipolar | - | 20.0 | 18° | 3V | - | - | Round - 0.134" Dia (3.40mm) | - | 0.024" (0.60mm) | -10°C ~ 50°C | - | PC Pin | - | 25 Ohms | Round Shaft |
|
|
82910502STEPPER MOTOR PM UNIPOLAR 17V |
1,922 |
|
Datasheet |
82910 | Bulk | Active | Permanent Magnet | Unipolar | 140 mA | 24.0 | 15° | 17VDC | - | 2.1 / 15 | Round - 1.409" Dia (35.80mm) | - | 0.079" (2.00mm) | - | 0.354" (9.00mm) | Wire Leads | 1.650" (42.00mm) | 115 Ohms | Round Shaft |
|
|
82910001STEPPER MOTOR PM BIPOLAR 4.7V |
2,530 |
|
Datasheet |
82910 | Bulk | Active | Permanent Magnet | Bipolar | 520 mA | 48.0 | 7.5° | 4.7VDC | ±5% | 3.5 / 25 | Round - 1.409" Dia (35.80mm) | - | 0.079" (2.00mm) | - | 0.354" (9.00mm) | Wire Leads | 1.650" (42.00mm) | 9 Ohms | - |
