Home > Products  > Integrated Circuits (ICs) > Linear > Audio Amplifiers
MAX4062EUB+

OEM STOCK

Analog Devices Inc./Maxim Integrated MAX4062EUB+Sell Excess Inventory

Part No.:
MAX4062EUB+
Manufacturer:
Analog Devices Inc./Maxim Integrated
Category:
Audio Amplifiers
Package:
10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
Datasheet:
OEM STOCKMAX4062EUB+.pdf
Description:
IC AMP CLASS AB STEREO 10UMAX
Quantity:

Unit Price:$0

Ext Price:$0

Payment
Payment
Shipping
Shipping

Product details

General Description

The MAX4062EUB+ are differential-input microphone preamplifiers optimized for notebook and PDA audio systems. These devices feature adjustable gain with excellent power-supply rejection and commonmode rejection ratios, making them ideal for lownoise applications in portable audio systems. The MAX4062EUB+ are capable of switching their output between the differential input and a single-ended auxiliary microphone amplifier input.

In addition, the MAX4060/MAX4062 have a low-noise microphone bias generator. The differential gain of the MAX4062EUB+ is set with a single resistor. The MAX4062EUB+ has a fixed gain of 10V/V and is PC99/2001 compliant. The MAX4062EUB+ includes a complete shutdown mode. In shutdown, the supply current is reduced to 0.3μA and the current to the microphone bias is cut off for ultimate power savings. The MAX4062EUB+operates from a 4.5V to 5.5V single supply and the MAX4062EUB+ operate from 2.4V to 5.5V. All devices are specified over the extended operating temperature range, -40°C to +85°C. The MAX4062EUB+ are available in tiny 8-pin TDFN (3mm x 3mm x 0.8mm) and 8-pin μMAX® packages. The MAX4062 is available in a 10-pin μMAX package.

MAX4062EUB+ Features

2.4V to 5.5V Single-Supply Operation

Adjustable Gain or Fixed-Gain Options

High PSRR (86dB at 1kHz)

High CMRR (70dB at 1kHz)

Low Input-Referred Noise

Integrated Microphone Bias

750μA Supply Current

0.3μA Shutdown Current

±4kV ESD Protection (AUX_IN)

Rail-to-Rail Outputs

THD+N: 0.04% at 1kHz

MAX4062EUB+ Applications

Notebook Audio Systems

Tablet PCs

PDA Audio Systems

USB Audio Peripherals

AES-42-Compliant Microphones

Signal Conditioning

Typical Operating Circuit

MAX4062EUB+ Typical Operating Circuit


Equivalent

Equivalent products of MAX4062EUB+ chip are: 1. MAX4062EUB+T 2. MAX4062EUB+TG035 3. MAX4062EUB+TG035E3 4. MAX4062EUB+TG035E3+ 5. MAX4062EUB+TG035E4+ These are variations of the MAX4062EUB+ chip with different specifications, such as temperature range or package type.


Pinout

The MAX4062EUB+ is a 10-pin, ultra-low power op-amp with a gain bandwidth of 2.7MHz. It features a shutdown mode to reduce power consumption and is suitable for battery-powered applications. The pin functions include input, output, positive power supply, negative power supply, and shutdown control.

Package

The MAX4062EUB+ chip is offered in a MSOP package type, with a form of Surface Mount and a size of 8-UMAX.

Manufacturer

The MAX4062EUB+ is manufactured by Maxim Integrated, an American company specializing in designing, manufacturing, and selling analog and mixed-signal integrated circuits. Maxim Integrated primarily focuses on providing power management, amplification, and analog ICs for a wide range of applications, including automotive, industrial, consumer, and communications markets.


  • Specifications
  • FAQ
  • Purchase & Inquiry
Attributes
Property Value
Manufacturer
Analog Devices Inc./Maxim Integrated
Series:
-
Package/Case:
10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
Packaging:
Tube
Part Status:
Active
Type:
Class AB
Output Type:
2-Channel (Stereo)
Voltage - Supply:
2.4V ~ 5.5V
Features:
Differential Inputs, Microphone
Mounting Style:
Surface Mount
Max Output Power x Channels @ Load:
-
Operating Temperature:
-40°C ~ 85°C (TA)
Grade:
-
Qualification:
-
Supplier Device Package:
10-uMAX/uSOP
Category:
Audio Amplifiers
