VersaLogic Corporation VL-CBR-4005ASell Excess Inventory

Part No.:: VL-CBR-4005A

Manufacturer:: VersaLogic Corporation

Category:: Embedded Computer Accessories

Package:

Datasheet:: VL-CBR-4005A.pdf

Description:: 12" 1 MM 40-PIN TO 40-PIN PICO-C

Quantity:: RFQ Add To RFQ list Buy Now Add To Cart

Unit Price:$0

Ext Price:$0

Payment

Shipping

Product details

VL-CBR-4005A - 12-inch 40-Pin to 40-Pin Pico-C Cable (1.0 mm Pitch)

VL-CBR-4005A is a high-quality Pico-C interconnect cable from VersaLogic, designed to provide reliable board-to-board connectivity for embedded and industrial systems. The cable features a 40-pin to 40-pin configuration, 1.0 mm pitch, and a 12-inch (305 mm) length, optimized for compact enclosures and rugged deployments.

Product Introduction

The VL-CBR-4005A is a flexible Pico-C cable assembly used to interconnect embedded carrier boards, expansion modules, or I/O boards that utilize Pico-C headers. It is commonly deployed in VersaLogic embedded computers and compatible third-party systems.

With its 40-pin straight-through pinout, this cable supports a wide range of signals including data, control, and power rails, depending on the connected Pico-C interface definition. The controlled pitch and cable construction help maintain signal integrity in dense embedded layouts.

The 12-inch length provides sufficient flexibility for internal routing within compact enclosures while avoiding excessive slack that could impact airflow or mechanical reliability.

Key Benefits

Standard Pico-C Compatibility

Designed for 1.0 mm pitch Pico-C connectors, ensuring mechanical and electrical compatibility with VersaLogic and industry-standard Pico-C interfaces.

Optimized Cable Length

The 12-inch length balances routing flexibility and signal integrity in space-constrained embedded enclosures.

Reliable Signal Transmission

Manufactured with consistent conductor spacing to support stable transmission of high-speed digital and control signals.

Industrial-Grade Construction

Suitable for embedded and industrial environments where vibration resistance and long-term reliability are required.

Technical Features

Connector Configuration

40-pin to 40-pin Pico-C, straight-through cable assembly.

Pitch Specification

1.0 mm pitch suitable for high-density embedded interconnects.

Cable Length

12 inches (approximately 305 mm).

Mechanical Flexibility

Flexible flat cable design allows routing around internal structures without excessive stress on connectors.

Signal Support

Supports mixed-signal usage including digital data, control, and low-power rails, depending on interface definition.

Embedded System Integration

Qualified for use in embedded computers, carrier boards, and expansion modules.

Technical Specifications

Parameter	Specification
Part Number	VL-CBR-4005A
Manufacturer	VersaLogic Corporation
Product Type	Pico-C Interconnect Cable
Connector Type	Pico-C
Pin Count	40-pin to 40-pin
Pitch	1.0 mm
Cable Length	12 inches (305 mm)
Pin Mapping	Straight-through
Application Environment	Embedded / Industrial systems
Compliance	RoHS compliant

Interface & Usage Notes

The VL-CBR-4005A does not define signal functionality by itself; signal usage is determined by the connected Pico-C interfaces on the host and peripheral boards. Typical Pico-C usage includes combinations of GPIO, serial interfaces, control signals, and low-voltage power.

Designers should verify pin assignments and current ratings according to their specific board documentation before installation.

Equivalent & Manufacturer Information

Equivalent / Alternative Options

Equivalent Pico-C cables should match the following parameters:

40-pin Pico-C connector on both ends
1.0 mm pitch
Straight-through pin mapping
Comparable cable length and mechanical flexibility

Custom cable assemblies may be used, but should be validated for signal integrity and mechanical fit.

About VersaLogic

VersaLogic is a leading provider of rugged embedded computing platforms, accessories, and qualified components designed for long-life and industrial applications.

Application Field

Embedded Computers

Internal board-to-board connections.

Industrial Controllers

Reliable interconnects in control systems.

Expansion Modules

Pico-C based I/O expansion.

Custom Embedded Platforms

Flexible internal signal routing.

Quality, Handling & Traceability

Incoming inspection: visual inspection of connectors, cable jacket, and labeling.
Handling: avoid sharp bends and excessive pull force on connectors.
Traceability: maintain part number and supplier records for industrial deployments.

Disclaimer

Specifications and usage descriptions are provided for reference only. Actual electrical characteristics depend on the connected Pico-C interfaces and system design. Always validate compatibility before deployment in production systems.

Specifications
FAQ
Purchase & Inquiry

Attributes: Property Value

Manufacturer: VersaLogic Corporation

Series:: -

Packaging:: Bulk

Part Status:: Active

Accessory Type:: Cable

Specifications:: 12" Pico-Clasp 40-Pin to 40-Pin

Category:: Embedded Computer Accessories
