Mfr. Part #	Availability	Price	Quantity	Datasheet	Series	Packaging	Part Status	Circuit	Switch Function	Voltage Rating - AC	Voltage Rating - DC	Actuator Type	Current Rating (Amps)	Mounting Style	Termination Style	Ingress Protection	Features	Operating Force	Differential Travel	Release Force	Pretravel	Operating Position	Overtravel	Operating Temperature
D2QW-C183D SWITCH SNAP ACTION SUBMINI BASIC Omron Electronics Inc-EMC Div	4,889	-	RFQ Sell Excess Inventory	Datasheet	*	Bulk	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
D2QW-C172D SWITCH SNAP ACTION SUBMINI BASIC Omron Electronics Inc-EMC Div	3,847	-	RFQ Sell Excess Inventory	Datasheet	*	Bulk	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
V7-6C18D8-002 SWITCH SNAP ACTION SPDT 15A 125V Honeywell Sensing and Productivity Solutions	3,567	-	RFQ Sell Excess Inventory	Datasheet	V7	Bulk	Active	SPDT	On-Mom	125 V	125 V	Lever, Straight	15A (AC), 500mA (DC)	Chassis Mount	Quick Connect - 0.187" (4.7mm)	-	-	413gf	0.014" (0.35mm)	-	0.063" (1.6mm)	0.602" (15.3mm)	0.035" (0.9mm)	-40°C ~ 85°C
V7-6C27D8-048 SWITCH SNAP ACT SPST-NO 15A 125V Honeywell Sensing and Productivity Solutions	1,295	-	RFQ Sell Excess Inventory	Datasheet	V7	Bulk	Active	SPST-NO	Off-Mom	125 V	125 V	Lever, Straight	15A (AC), 500mA (DC)	Chassis Mount	Quick Connect - 0.187" (4.7mm)	-	-	120gf	0.055" (1.4mm)	20gf	0.250" (6.35mm)	0.579" (14.7mm)	0.125" (3.2mm)	-40°C ~ 85°C
TMCJG6ST1440C SWITCH SNAP ACTION SPDT 15A 125V C&K	2,773	-	RFQ Sell Excess Inventory	Datasheet	TM	Bulk	Active	SPDT	On-Mom	125 V	125 V	Lever, Simulated Roller	15A (AC), 500mA (DC)	Chassis Mount	Quick Connect - 0.187" (4.7mm)	-	-	90gf	0.050" (1.3mm)	20gf	0.140" (3.6mm)	0.745" (18.9mm)	0.062" (1.6mm)	-55°C ~ 150°C
VX-01-2A3 SWITCH SNP ACT SPST-NC 0.1A 125V Omron Electronics Inc-EMC Div	4,980	-	RFQ Sell Excess Inventory	Datasheet	VX	Tray	Active	SPST-NC	On-Mom	125 V	30 V	Round (Pin Plunger)	100mA (AC/DC)	Chassis Mount	Solder, Quick Connect - 0.187" (4.7mm)	IP40	-	50gf	0.012" (0.3mm)	5.000gf	0.047" (1.2mm)	0.579" (14.7mm)	0.039" (1.0mm)	-25°C ~ 105°C
AV630564 SWITCH SNAP ACT SPST-NO 0.1A 30V Panasonic Electric Works	3,584	-	RFQ Sell Excess Inventory	Datasheet	AV6	Bulk	Active	SPST-NO	Off-Mom	-	30 V	Round (Pin Plunger)	100mA (DC)	Chassis Mount	Connector	IP40	-	153gf	0.004" (0.1mm)	25gf	0.024" (0.6mm)	0.330" (8.4mm)	0.015" (0.4mm)	-25°C ~ 85°C
V7-1C27D94 SWITCH SNAP ACT SPST-NO 15A 125V Honeywell Sensing and Productivity Solutions	1,978	-	RFQ Sell Excess Inventory	Datasheet	V7	Bulk	Active	SPST-NO	Off-Mom	125 V	125 V	Round (Pin Plunger)	15A (AC), 500mA (DC)	Chassis Mount	Quick Connect - 0.250" (6.3mm)	-	-	150gf	0.010" (0.25mm)	25gf	0.047" (1.2mm)	0.579" (14.7mm)	0.050" (1.27mm)	-40°C ~ 85°C
DS2D6AQ2 SWITCH SNAP ACTION DPDT 10A 125V C&K	2,138	-	RFQ Sell Excess Inventory	Datasheet	DS	Bulk	Active	DPDT	On-Mom	125 V	-	Round (Pin Plunger)	10A (AC)	Panel Mount, Snap-In	Quick Connect - 0.187" (4.7mm)	-	-	680gf	-	-	-	0.350" (8.9mm)	0.125" (3.2mm)	-40°C ~ 85°C
D3V-165-1C4 SWITCH SNAP ACTION SPDT 16A 250V Omron Electronics Inc-EMC Div	3,755	-	RFQ Sell Excess Inventory	Datasheet	D3V	Bulk	Active	SPDT	On-Mom	250 V	125 V	Lever, Roller	16A (AC), 600mA (DC)	Chassis Mount	Quick Connect - 0.250" (6.3mm)	IP40	-	120gf	0.025" (0.6mm)	15gf	0.063" (1.6mm)	0.815" (20.7mm)	0.031" (0.79mm)	-25°C ~ 105°C
TF316CJP0040Y SWITCH SNAP ACT SPST-NO 16A 125V C&K	3,365	-	RFQ Sell Excess Inventory	Datasheet	TF2	Bulk	Active	SPST-NO	Off-Mom	125 V	-	Round (Pin Plunger)	16A (AC)	Chassis Mount	Quick Connect - 0.187" (4.7mm)	-	-	842gf	0.047" (1.2mm)	-	0.075" (1.9mm)	0.567" (14.4mm)	0.026" (0.7mm)	-40°C ~ 125°C
D2HW-ER211H BY OMR SWITCH SNAP ACTION SUBMINI BASIC Omron Electronics Inc-EMC Div	4,561	-	RFQ Sell Excess Inventory	Datasheet	*	Bulk	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
D2QW-C162H SWITCH SNAP ACTION SUBMINI BASIC Omron Electronics Inc-EMC Div	3,708	-	RFQ Sell Excess Inventory	Datasheet	*	Bulk	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
D2QW-C163D SWITCH SNAP ACTION SUBMINI BASIC Omron Electronics Inc-EMC Div	3,859	-	RFQ Sell Excess Inventory	Datasheet	*	Bulk	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
D2HW-C241HS SUBMINIATURE BASIC SWITCH Omron Electronics Inc-EMC Div	3,172	-	RFQ Sell Excess Inventory	Datasheet	D2HW	Bulk	Active	SPDT	On-Mom	125 V	12 V	Lever, Roller	100mA (AC), 2A (DC)	Chassis Mount	Solder Lug	IP67 - Dust Tight, Waterproof	-	66gf	0.025" (0.6mm)	3.059gf	-	0.551" (14.0mm)	0.075" (1.9mm)	-40°C ~ 85°C
V-161-1A5 SWITCH SNAP ACTION MINI BASIC Omron Electronics Inc-EMC Div	3,282	-	RFQ Sell Excess Inventory	Datasheet	*	Bulk	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
VX-53K-1A3 SWITCH SNAP ACTION SPDT 5A 125V Omron Electronics Inc-EMC Div	1,894	-	RFQ Sell Excess Inventory	Datasheet	VX	Bulk	Active	SPDT	On-Mom	125 V	30 V	Lever, Straight	5A (AC/DC)	Chassis Mount	Solder Lug	IP40	-	20gf	0.165" (4.2mm)	-	0.591" (15.0mm)	0.598" (15.2mm)	0.197" (5.0mm)	-25°C ~ 80°C
V7-3S17D8-000-3 SWITCH SNAP ACT SPDT 0.1A 125V Honeywell Sensing and Productivity Solutions	2,624	-	RFQ Sell Excess Inventory	Datasheet	V7	Bulk	Obsolete	SPDT	On-Mom	125 V	-	Round (Pin Plunger)	100mA (AC)	Chassis Mount	Quick Connect - 0.187" (4.7mm)	-	-	50gf	0.006" (0.15mm)	5.000gf	0.047" (1.2mm)	0.579" (14.7mm)	0.050" (1.27mm)	-40°C ~ 85°C
TFCJJ3ST254AC BASIC / SNAP ACTION SWITCHES C&K	2,439	-	RFQ Sell Excess Inventory	Datasheet	TF	Bulk	Active	SPDT	On-Mom	277 V	-	Lever, Straight	21A (AC)	Chassis Mount	Quick Connect - 0.250" (6.3mm)	-	-	45gf	0.055" (1.4mm)	6.000gf	0.250" (6.35mm)	0.600" (15.2mm)	0.125" (3.2mm)	-40°C ~ 85°C
HY15-6Y7-091-0311 SWITCH SNAP ACTION DPST 18A 125V E-Switch	3,323	-	RFQ Sell Excess Inventory	Datasheet	HY	Bulk	Active	DPST-NO/NC	On-Mom, Off-Mom	125 V	-	Trigger	18A (AC)	Panel Mount	Screw Terminal	-	-	3000gf	-	-	-	-	-	-
