Mfr. Part #	Availability	Price	Quantity	Datasheet	Series	Packaging	Part Status	Circuit	Switch Function	Voltage Rating - AC	Voltage Rating - DC	Actuator Type	Current Rating (Amps)	Mounting Style	Termination Style	Ingress Protection	Features	Operating Force	Differential Travel	Release Force	Pretravel	Operating Position	Overtravel	Operating Temperature
D3V-166-1C4 SWITCH SNAP ACTION SPDT 16A 250V Omron Electronics Inc-EMC Div	4,299	-	RFQ Sell Excess Inventory	Datasheet	D3V	Bulk	Active	SPDT	On-Mom	250 V	125 V	Lever, Roller	16A (AC), 600mA (DC)	Chassis Mount	Quick Connect - 0.250" (6.3mm)	IP40	-	60gf	0.060" (1.5mm)	6.118gf	0.157" (4.0mm)	0.815" (20.7mm)	0.062" (1.6mm)	-25°C ~ 105°C
V7-1Y39E9 SWITCH SNAP ACT SPST-NC 20A 277V Honeywell Sensing and Productivity Solutions	2,527	-	RFQ Sell Excess Inventory	Datasheet	V7	Bulk	Active	SPST-NC	On-Mom	277 V	-	Round (Pin Plunger)	20A (AC)	Chassis Mount	Quick Connect - 0.250" (6.3mm)	-	-	65 ~ 125gf	0.010" (0.25mm)	20gf	0.047" (1.2mm)	0.579" (14.7mm)	0.050" (1.27mm)	-40°C ~ 85°C
SSG-01T-5 SWITCH SNAP ACT SPDT 0.1A 125V Omron Electronics Inc-EMC Div	2,739	-	RFQ Sell Excess Inventory	Datasheet	SSG	Bulk	Active	SPDT	On-Mom	125 V	30 V	Round (Pin Plunger)	100mA (AC/DC)	Chassis Mount	Quick Connect - 0.110" (2.8mm)	IP40	-	51gf	0.004" (0.1mm)	4.079gf	0.024" (0.6mm)	0.330" (8.4mm)	0.015" (0.4mm)	-25°C ~ 125°C
D2SW-01L2DS SWITCH SNAP ACT SPDT 0.1A 125V Omron Electronics Inc-EMC Div	1,112	-	RFQ Sell Excess Inventory	Datasheet	D2SW	Tray	Active	SPDT	On-Mom	125 V	30 V	Lever, Roller	100mA (AC/DC)	Through Hole	PC Pin	IP67 - Dust Tight, Waterproof	-	60gf	0.031" (0.8mm)	6.118gf	-	0.571" (14.5mm)	0.040" (1.0mm)	-40°C ~ 85°C
ABJ263240 SWITCH SNAP ACT SPST-NO 1A 125V Panasonic Electric Works	4,345	-	RFQ Sell Excess Inventory	Datasheet	ABJ	Bulk	Active	SPST-NO	Off-Mom	125 V	30 V	Lever, Straight	1A (AC/DC)	Chassis Mount	Wire Leads	IP67 - Dust Tight, Waterproof	-	40gf	0.020" (0.5mm)	3.000gf	0.118" (3.0mm)	0.327" (8.3mm)	0.020" (0.5mm)	-40°C ~ 85°C
HY106-6Y7-000-0000 SWITCH SNAP ACTION DPST 18A 250V E-Switch	1,389	-	RFQ Sell Excess Inventory	Datasheet	HY	Bulk	Active	DPST-NO/NC	On-Mom, Off-Mom	250 V	-	Plunger for Cap	18A (AC)	Panel Mount	Screw Terminal	-	-	3000gf	-	-	-	-	-	0°C ~ 55°C
V15S11-UZ200 BASIC SWITCH Honeywell Sensing and Productivity Solutions	4,913	-	RFQ Sell Excess Inventory	Datasheet	V15	Bulk	Active	SPDT	On-Mom	125 V	-	Round (Pin Plunger)	11A (AC)	Chassis Mount	Screw Terminal	-	-	200gf	0.020" (0.51mm)	50gf	0.060" (1.5mm)	0.579" (14.7mm)	0.030" (0.76mm)	-25°C ~ 85°C
V7-1A17D8-000-1 SWITCH PLUNGER SPDT 5A QC Honeywell Sensing and Productivity Solutions	3,395	-	RFQ Sell Excess Inventory	Datasheet	V7	Bulk	Obsolete	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
PP2-1H1-2A2 Switches E-Switch	1,238	-	RFQ Sell Excess Inventory	Datasheet	PP2	Bulk	Active	DPDT	On-Mom	277 V	-	Round (Pin Plunger)	10A (AC)	Panel Mount, Snap-In	Quick Connect - 0.187" (4.7mm)	-	-	-	-	-	-	-	-	0°C ~ 85°C
MBZ106B01C06B01 SNAP ACTING SWITCH MB APEM Inc.	3,007	-	RFQ Sell Excess Inventory	Datasheet	MBZ	Bulk	Active	SPDT	On-Mom	-	12 V	Lever, Roller	100mA (DC)	Chassis Mount	Solder Lug	-	-	153gf	0.040" (1.0mm)	-	0.197" (5.0mm)	0.638" (16.2mm)	0.059" (1.5mm)	-40°C ~ 85°C
MBZ106A01C06B01 SNAP ACTING SWITCH MB APEM Inc.	2,320	-	RFQ Sell Excess Inventory	Datasheet	MBZ	Bulk	Active	SPDT	On-Mom	-	12 V	Lever, Roller	100mA (DC)	Chassis Mount	Solder Lug	-	-	285gf	0.040" (1.0mm)	-	0.197" (5.0mm)	0.638" (16.2mm)	0.059" (1.5mm)	-40°C ~ 85°C
AV620264 SWITCH SNAP ACT SPST-NC 0.1A 30V Panasonic Electric Works	1,580	-	RFQ Sell Excess Inventory	Datasheet	AV6	Bulk	Active	SPST-NC	On-Mom	-	30 V	Round (Pin Plunger)	100mA (DC)	Chassis Mount	Connector	IP40	-	51gf	0.004" (0.1mm)	4.079gf	0.024" (0.6mm)	0.330" (8.4mm)	0.015" (0.4mm)	-25°C ~ 85°C
G01293589 Linear IC's C&K	3,942	-	RFQ Sell Excess Inventory	Datasheet	ZMT	Bulk	Active	SPST-NO	Off-Mom	125 V	24 V	Lever, Leaf	3A (AC/DC)	Chassis Mount	Wire Leads	IP67 - Dust Tight, Waterproof	-	56gf	-	8gf	0.134" (3.4mm)	0.280" (7.1mm)	0.024" (0.6mm)	-40°C ~ 85°C
UM50E70F01 SWITCH SNAP ACTION SPDT 5A 250V Honeywell Sensing and Productivity Solutions	1,971	-	RFQ Sell Excess Inventory	Datasheet	UM	Bulk	Obsolete	SPDT	On-Mom	250 V	-	Lever, Roller	5A (AC)	Chassis Mount	Quick Connect - 0.110" (2.8mm)	-	-	60gf	0.020" (0.5mm)	4.000gf	0.100" (2.5mm)	0.571" (14.5mm)	0.030" (0.76mm)	-25°C ~ 82°C
V-106-1C4 SWITCH SNAP ACTION SPDT 10A 250V Omron Electronics Inc-EMC Div	1,027	-	RFQ Sell Excess Inventory	Datasheet	V	Bulk	Active	SPDT	On-Mom	250 V	125 V	Lever, Roller	10A (AC), 600mA (DC)	Chassis Mount	Quick Connect - 0.250" (6.3mm)	IP40	-	60gf	0.060" (1.5mm)	6.118gf	0.157" (4.0mm)	0.815" (20.7mm)	0.062" (1.6mm)	-25°C ~ 80°C
DS2D6AQ3 SWITCH SNAP ACTION DPDT 10A 125V C&K	2,223	-	RFQ Sell Excess Inventory	Datasheet	DS	Bulk	Active	DPDT	On-Mom	125 V	-	Round (Pin Plunger)	10A (AC)	Panel Mount, Snap-In	Quick Connect - 0.250" (6.3mm)	-	-	680gf	-	-	-	0.350" (8.9mm)	0.125" (3.2mm)	-40°C ~ 85°C
V7-2A18D8-207 SWITCH SNAP ACTION Honeywell Sensing and Productivity Solutions	3,035	-	RFQ Sell Excess Inventory	Datasheet	*	Bulk	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
ABV1220519 SWITCH SNAP ACT SPST-NC 3A 250V Panasonic Electric Works	3,507	-	RFQ Sell Excess Inventory	Datasheet	ABV	Bulk	Active	SPST-NC	On-Mom	250 V	-	Round (Pin Plunger)	3A (AC)	Chassis Mount	Solder, Quick Connect - 0.187" (4.7mm)	IP50 - Dust Protected	-	200gf	0.016" (0.4mm)	40gf	0.063" (1.6mm)	0.579" (14.7mm)	0.030" (0.76mm)	-40°C ~ 85°C
V7-1V39E9 SWITCH SNAP ACT SPST-NC 21A 125V Honeywell Sensing and Productivity Solutions	3,428	-	RFQ Sell Excess Inventory	Datasheet	V7	Bulk	Obsolete	SPST-NC	On-Mom	125 V	-	Round (Pin Plunger)	21A (AC)	Chassis Mount	Quick Connect - 0.250" (6.3mm)	-	-	175gf	0.010" (0.25mm)	20gf	0.047" (1.2mm)	0.579" (14.7mm)	0.050" (1.27mm)	-40°C ~ 85°C
V7-1C17E9-207 SWITCH SNAP ACTION SPDT 15A 125V Honeywell Sensing and Productivity Solutions	1,621	-	RFQ Sell Excess Inventory	Datasheet	V7	Bulk	Active	SPDT	On-Mom	125 V	125 V	Lever, Roller	15A (AC), 500mA (DC)	Chassis Mount	Quick Connect - 0.250" (6.3mm)	-	-	86gf	0.025" (0.6mm)	9.000gf	0.112" (2.85mm)	0.803" (20.4mm)	0.065" (1.7mm)	-40°C ~ 85°C
