Toggle Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Part Status | Mounting Style | Circuit | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Switch Function | Actuator Type | Actuator Length | Illumination | Illumination Type, Color | Illumination Voltage (Nominal) | Ingress Protection | Termination Style | Bushing Thread | Panel Cutout Dimensions | Features | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ATE2N-2M3-10-ZSWITCH TOGGLE DPDT 50MA 48V |
3,967 |
|
Datasheet |
ATE | Tray | Obsolete | Through Hole | DPDT | 50mA (AC/DC) | 48 V | 48 V | On-On | Standard Round | 6.00mm | Non-Illuminated | - | - | - | PC Pin | Unthreaded | - | Washable | -20°C ~ 85°C |
|
ATE2N-5M3-10-ZSWITCH TOGGLE DPDT 50MA 48V |
4,358 |
|
Datasheet |
ATE | Tray | Obsolete | Through Hole, Right Angle | DPDT | 50mA (AC/DC) | 48 V | 48 V | On-On | Standard Round | 6.00mm | Non-Illuminated | - | - | - | PC Pin | Unthreaded | - | Washable | -20°C ~ 85°C |
|
ATE2N-6M3-10-ZSWITCH TOGGLE DPDT 50MA 48V |
4,890 |
|
Datasheet |
ATE | Tray | Obsolete | Through Hole, Right Angle | DPDT | 50mA (AC/DC) | 48 V | 48 V | On-On | Standard Round | 6.00mm | Non-Illuminated | - | - | - | PC Pin | Unthreaded | - | Washable | -20°C ~ 85°C |
|
ATLE42D-6M3-ZSWITCH TOGGLE DPDT 50MA 48V |
2,374 |
|
Datasheet |
ATLE4 | Tray | Obsolete | Through Hole, Right Angle | DPDT | 50mA (AC/DC) | 48 V | 48 V | On-On | Locking Lever | 12.70mm | Non-Illuminated | - | - | - | PC Pin | Unthreaded | - | - | -20°C ~ 85°C |
|
|
ATLE42E-6M3-ZSWITCH TOGGLE DPDT 50MA 48V |
4,202 |
|
Datasheet |
ATLE4 | Tray | Obsolete | Through Hole, Right Angle | DPDT | 50mA (AC/DC) | 48 V | 48 V | On-Off-On | Locking Lever | 12.70mm | Non-Illuminated | - | - | - | PC Pin | Unthreaded | - | - | -20°C ~ 85°C |
|
ATLE44D-2M4-ZSWITCH TOGGLE 4PDT 50MA 48V |
4,889 |
|
Datasheet |
ATLE4 | Tray | Obsolete | Through Hole | 4PDT | 50mA (AC/DC) | 48 V | 48 V | On-On | Locking Lever | 12.70mm | Non-Illuminated | - | - | - | PC Pin | Unthreaded | - | - | -20°C ~ 85°C |
|
CFT2-1FC4-AWSWITCH TOGGLE SPDT 0.4VA 28V |
2,840 |
|
Datasheet |
CFT2 | Tray | Obsolete | Through Hole, Right Angle | SPDT | 0.4VA (AC/DC) | 28 V | 28 V | On-Mom | Standard Round | 3.80mm | Non-Illuminated | - | - | - | PC Pin | Unthreaded | - | Washable, Gray Actuator | -40°C ~ 85°C |
|
CFT2-1FC-AWSWITCH TOGGLE SPDT 0.4VA 28V |
2,535 |
|
Datasheet |
CFT2 | Tray | Obsolete | Through Hole | SPDT | 0.4VA (AC/DC) | 28 V | 28 V | On-Mom | Standard Round | 3.80mm | Non-Illuminated | - | - | - | PC Pin | Unthreaded | - | Washable, Gray Actuator | -40°C ~ 85°C |
|
CFT2-2NC6-AWSWITCH TOGGLE DPDT 0.4VA 28V |
3,152 |
|
Datasheet |
CFT2 | Tray | Obsolete | Through Hole, Right Angle, Vertical | DPDT | 0.4VA (AC/DC) | 28 V | 28 V | On-On | Standard Round | 3.80mm | Non-Illuminated | - | - | - | PC Pin | Unthreaded | - | Washable, Gray Actuator | -40°C ~ 85°C |
|
CFT2-2NC-AWSWITCH TOGGLE DPDT 0.4VA 28V |
3,158 |
|
Datasheet |
CFT2 | Tray | Obsolete | Through Hole | DPDT | 0.4VA (AC/DC) | 28 V | 28 V | On-On | Standard Round | 3.80mm | Non-Illuminated | - | - | - | PC Pin | Unthreaded | - | Washable, Gray Actuator | -40°C ~ 85°C |
|
|
CFT2-2PC-AWSWITCH TOGGLE DPDT 0.4VA 28V |
1,332 |
|
Datasheet |
CFT2 | Tray | Obsolete | Through Hole | DPDT | 0.4VA (AC/DC) | 28 V | 28 V | On-Off-On | Standard Round | 3.80mm | Non-Illuminated | - | - | - | PC Pin | Unthreaded | - | Washable, Gray Actuator | -40°C ~ 85°C |
|
CFT2-2RC-AWSWITCH TOGGLE DPDT 0.4VA 28V |
4,188 |
|
Datasheet |
CFT2 | Tray | Obsolete | Through Hole | DPDT | 0.4VA (AC/DC) | 28 V | 28 V | On-Mom | Standard Round | 3.80mm | Non-Illuminated | - | - | - | PC Pin | Unthreaded | - | Washable, Gray Actuator | -40°C ~ 85°C |
|
|
CFT2-2SC6-AWSWITCH TOGGLE DPDT 0.4VA 28V |
3,946 |
|
Datasheet |
CFT2 | Tray | Obsolete | Through Hole, Right Angle, Vertical | DPDT | 0.4VA (AC/DC) | 28 V | 28 V | Mom-Off-Mom | Standard Round | 3.80mm | Non-Illuminated | - | - | - | PC Pin | Unthreaded | - | Washable, Gray Actuator | -40°C ~ 85°C |
|
CFT2-2TC4-AWSWITCH TOGGLE DPDT 0.4VA 28V |
2,166 |
|
Datasheet |
CFT2 | Tray | Obsolete | Through Hole, Right Angle | DPDT | 0.4VA (AC/DC) | 28 V | 28 V | On-Off-Mom | Standard Round | 3.80mm | Non-Illuminated | - | - | - | PC Pin | Unthreaded | - | Washable, Gray Actuator | -40°C ~ 85°C |
|
TBS1T2A1MZRESSWITCH TOGGLE SPDT 0.4VA 20V |
1,991 |
|
Datasheet |
- | Tape & Reel (TR) | Obsolete | Surface Mount, Right Angle | SPDT | 0.4VA (AC/DC) | 20 V | 20 V | On-On | Standard Round | 6.10mm | Non-Illuminated | - | - | - | SMD (SMT) Tab | Unthreaded | - | Process Sealed | -30°C ~ 85°C |
|
|
P2021ESWITCH TOGGLE DPST 10A 125V |
2,457 |
|
Datasheet |
P | Bulk | Obsolete | Panel Mount | DPST | 10A (AC) | 125 V | - | On-Off | Flatted | 11.40mm | Non-Illuminated | - | - | - | Solder Lug | M6 x 0.75 | Circular - 6.35mm Dia | - | -10°C ~ 85°C |
|
3105DSWITCH TOGGLE SPST 6A 125V |
1,314 |
|
Datasheet |
3100 | Bulk | Active | Panel Mount | SPST | 6A (AC) | 125 V | - | On-Off | Standard Round | 14.22mm | Non-Illuminated | - | - | IP67 - Dust Tight, Waterproof | Wire Leads | 15/32-32 | - | - | -10°C ~ 65°C |
|
|
1-1825138-2SWITCH TOGGLE DPDT 5A 120V |
2,200 |
|
Datasheet |
Gemini A | Bulk | Active | Panel Mount, Right Angle | DPDT | 5A (AC/DC) | 120 V | 28 V | On-On | Standard Round | 5.08mm | Non-Illuminated | - | - | - | PC Pin | 1/4-40 | Circular - 6.35mm Dia | Epoxy Sealed Terminals | -30°C ~ 85°C |
|
|
1-1825139-5SWITCH TOGGLE DPDT 0.4VA 20V |
2,059 |
|
Datasheet |
Gemini A | Bulk | Obsolete | Through Hole, Right Angle | DPDT | 0.4VA (AC/DC) | 20 V | 20 V | Mom-Off-Mom | Standard Round | 12.19mm | Non-Illuminated | - | - | - | PC Pin | Unthreaded | - | Epoxy Sealed Terminals | -30°C ~ 85°C |
|
|
1825137-7SWITCH TOGGLE SPDT 5A 120V |
2,694 |
|
Datasheet |
Gemini A | Bulk | Obsolete | Through Hole, Right Angle | SPDT | 5A (AC/DC) | 120 V | 28 V | On-Off-On | Standard Round | 12.19mm | Non-Illuminated | - | - | - | PC Pin | Unthreaded | - | Epoxy Sealed Terminals | -30°C ~ 85°C |
