The MIC2102YML-TR is part of Microchip's high-speed POL controller family featuring adaptive on-time control, integrated drivers and advanced protection features. Below are the major technical highlights relevant to engineers.
The controller uses a proprietary adaptive on-time architecture that enables ultra-fast transient response with minimal external compensation. This minimizes output deviation during load steps and supports very small output capacitors.
Supports switching frequencies up to 1 MHz, allowing compact inductors, reduced filter size and efficient power-density-optimized design.
Features high-current high-side and low-side drivers that reduce external component count and improve efficiency across load conditions.
Includes cycle-by-cycle current limit, under-voltage lockout (UVLO), thermal shutdown, short-circuit protection and bootstrap under-voltage protection for robust operation.
The controller maintains tight output voltage regulation, low ripple and stable operation even with fast load transients, making it suitable for sensitive digital core rails.
Offered in a small MSOP-10 package, enabling compact PCB layout and high component density in power modules and multi-rail designs.
| Input Voltage Range | 3 V – 28 V (controller supply) |
|---|---|
| Output Voltage | Adjustable down to 0.6 V (reference) |
| Switching Frequency | Up to 1 MHz (adaptive on-time architecture) |
| Gate Driver Capability | High-side & low-side MOSFET drivers integrated |
| Typical Operating Current | ~2 mA depending on switching frequency |
| Protection Features | OCP, UVLO, thermal shutdown, short-circuit protection |
| Package | 10-Pin MSOP (ML package), RoHS compliant |
| Operating Temperature Range | −40 °C to +125 °C (industrial) |
The 10-pin MSOP layout includes the following main functions:
• VDD – Bias supply input
• DH – High-side drive output
• DL – Low-side drive output
• VIN – Power-stage input
• CS – Current sense
• FB – Feedback regulation input
• EN – Enable / shutdown control
• PGND – Power ground
• AGND – Analog ground
• BOOT – Bootstrap driver supply
The MIC2102YML-TR is packaged in a compact 10-pin MSOP outline, which enables dense POL power stages and simplifies placement near microprocessors or FPGAs.
Mechanical data such as lead pitch, body width and recommended PCB pad dimensions should follow Microchip's package drawing to ensure proper soldering and thermal performance.
CPU, GPU, DSP, ASIC and FPGA core power supplies requiring fast transient response.
Used for switch/router ASICs, SerDes, PHYs and other high-speed digital subsystems.
POL conversion for PLCs, drives, motor-control units and industrial computing modules.
High-efficiency compact DC/DC stages for embedded boards, IoT gateways and smart devices.
Equivalent devices include other adaptive on-time synchronous buck controllers such as:
• Texas Instruments TPS40170 series
• ON Semiconductor NCP3020 family
• Analog Devices ADP18xx controllers
Microchip Technology is a leading semiconductor manufacturer specializing in power management ICs, microcontrollers, connectivity solutions and analog devices widely trusted in industrial, automotive and embedded applications.
We currently provide peer-to-peer order processing. Submit an RFQ for MIC2102YML-TR, and our professional agent will contact you with competitive global pricing and guide you to complete the order once you accept the offer.
Our experienced QC team strictly verifies and tests MIC2102YML-TR. Only qualified suppliers who pass our audit can list MIC2102YML-TR on OEM STOCK GLOBAL LIMITED. We pay close attention to sourcing channels and product quality so you can purchase with confidence.
Pricing and inventory for MIC2102YML-TR fluctuate and are updated periodically (typically within 24 hours). Quotations generally remain valid for 5 days unless otherwise stated.
Wire Transfer, PayPal, Alipay, WeChat Pay, Credit Card, Western Union, MoneyGram, and Escrow are supported. Note: Some payment methods may incur a handling fee.
We support DHL, UPS, FedEx, TNT, and Registered Mail. Shipping insurance is available. After dispatch, you will receive an email with tracking information. Note: Carriers may take up to 24 hours to show tracking events. Typical transit time: 3–5 days by express; 25–60 days by registered mail.
We perform Pre-Shipment Inspection (PSI) on randomly selected units before shipping. If there is an issue with MIC2102YML-TR, returns/replacements are accepted when:
Steps: (1) Inform us within 90 days; (2) Obtain Return Authorization (RMA) before sending items back.
Please contact us for technical documents and support related to Microchip Technology MIC2102YML-TR, including pin diagrams and datasheets. Our team will respond promptly.
