The PGA4311U is a high-performance, digitally controlled analog volume control IC intended for premium audio paths. It offers four independent channels with programmable gain from +31.5 dB down to −95.5 dB in 0.5 dB steps, allowing very fine control of stereo or multi-channel levels.
Each channel includes an internal high-quality audio op amp that can drive 600–660 Ω loads directly, eliminating the need for external buffers in many designs. Separate analog and digital supplies help isolate noise and maintain signal integrity, making the device suitable for mastering-grade equipment.
With its SPI interface, zero-cross detection option and compact SOIC-28 package, the PGA4311U simplifies the design of digital mixers, pre-amplifiers, DAC output stages and other audio products where both sound quality and precise channel matching are essential.
Low THD+N and wide dynamic range keep the original signal character intact, so the volume control stage does not become the weak link in a high-fidelity signal chain.
0.5 dB gain steps across a wide adjustment range allow accurate channel matching, scene recall and remote control via SPI, ideal for digitally managed systems.
Integrated amplifiers can directly drive low-impedance loads such as 600 Ω lines or headphone stages in many applications, reducing external component count and board space.
Separate analog and digital supplies, configurable zero-cross detection and standard SPI timing make it easy to integrate the PGA4311U with DSPs, Microcontrollers or control FPGAs.
Four fully independent channels support stereo, 2.1 or surround-preamp architectures, all controlled by a single SPI interface.
Gain adjustable from approximately +31.5 dB to −95.5 dB with 0.5 dB steps, enabling coarse trim, fine calibration and full mute control in one device.
Optional zero-cross detection can be enabled so level changes occur near signal zero crossings, helping to minimize audible clicks and pops when adjusting volume.
| Parameter | Value / Condition |
|---|---|
| Function | Digitally controlled 4-channel audio volume control |
| Gain Range | +31.5 dB to −95.5 dB (0.5 dB steps) |
| Control Interface | SPI serial interface (SDI, SDO, SCLK, CS) |
| Load Drive Capability | Capable of driving ≈600–660 Ω loads directly |
| Analog Supply | Typically ±5 V analog rails for maximum headroom |
| Digital Supply | Separate low-voltage digital supply for logic and SPI |
| Package | SOIC-28 (PGA4311U) |
